9. OUTLINE DRAWINGS
9 - 15
(e) MR-J4-700B4(-RJ)
[Unit: mm]
200
172
160
66
7.5
285
6
Cooling fan
exhaust
2-φ6 mounting hole
Approx.
38.5
Approx.
101
Approx. 80
Approx. 28
TE3
TE1
TE2
PE
6
300
7.5
With
MR-BAT6V1SET
Built-in regenerative resistor
lead terminal fixing screw
Screw size: M4
Tightening torque: 1.2 [N•m]
Intake
Mass: 6.5 [kg]
TE1
TE2
Screw size: M4
Tightening torque: 1.2 [N•m]
Screw size: M3.5
Tightening torque: 0.8 [N•m]
PE
TE3
PE
Screw size: M4
Tightening torque: 1.2 [N•m]
Screw size: M4
Tightening torque: 1.2 [N•m]
N- P3 P4TE3
L2 L3L1 CP+
TE1
VWU
L11 L21TE2
Terminal
Mounting screw
Screw size: M5
Tightening torque: 3.24 [N•m]
0.5160
Approx. 300
285 0.5
Mounting hole process drawing
Approx.
7.5
Approx.
7.5
4-M5 screw
Approx. 6Approx. 6
Approx. 172
