App. - 9
A
PPENDI
X
App. 5.4 OUTLINE DRAWINGS (Chapter 10 OUTLINE DRAWINGS)
[Unit: mm]
Approx.14
6
21.4
Approx.68
6
6
45
6
mounting hole
Approx.80 195
168
78
6
156
6
6
90
85
With MR-J3BAT
Approx.
25.5
Cooling fan
air intake
Cooling fan
Cooling fan
Exhaust
Mass: 2.3 [kg] (5.07 [lb])
U
V
W
CNP3
P
C
D
L
11
L21
CNP2
L
1
L
2
L3
N
P
1
P2
CNP1
Terminal signal layout
PE terminal
Screw size: M4
Tightening torque:
1.2 [N m] (10.6 [lb in])
3-M5 screw
Approx. 90
78 0.3
Approx. 6
Mounting hole process drawing
Mounting screw
Screw size: M5
Tightening torque: 3.24[N m] (28.7[lb in])
Approx. 6
