15 - 74
15. SERVO AMPLIFIERS WITH A LARGE CAPACITY
(
30k TO 55kW
)
15.9.2 Regenerative option
CAUTION
The specified combinations of regenerative options, converter unit and drive unit
may only be used. Otherwise, a fire may occur.
POINT
The calculation method of regenerative energy is the same as that for servo
amplifiers with 22kW or less. Refer to section 12.2 (2).
(1) Combination and regenerative power
The regenerative power values in the table are the regenerative power of the resistor and are not the rated
power.
Converter unit Drive unit
Regenerative power [W]
MR-RB139
(1.3
)
(Note 1) Three
MR-RB137
(1.3
) in parallel
MR-RB136-4
(5
)
(Note 2) Three
MR-RB138-4
(5
) in parallel
MR-J3-CR55K
MR-J3-DU30KA
1300 3900
MR-J3-DU37KA
MR-J3-DU30KA4
1300 3900 MR-J3-CR55K4
MR-J3-DU37KA4
MR-J3-DU45KA4
MR-J3-DU55KA4
Note. 1. The composite resistance value of three options is 1.3 . The resistance value of each is 4 .
2. The composite resistance value of three options is 5
. The resistance value of each is 15 .
(2) Parameter setting
POINT
Make sure to set parameter No.PA02 of the drive unit to " 00" (Not used)
since the regenerative option cannot be connected to the drive unit.
When using the regenerative option, set the parameter of the converter unit. Match parameter No.PA01 to
the regenerative option used.
Regenerative option selection
00: Not used
01: MR-RB139
02: MR-RB137 (3 pcs.)
11: MR-RB136-4
12: MR-RB138-4 (3 pcs.)
Parameter No.PA01
00
(3) Regenerative loss of drive unit and servo motor
Drive unit Inverse efficiency [ ] C charge [J]
MR-J3-DU30KA
MR-J3-DU37KA
MR-J3-DU30KA4
90 450
MR-J3-DU37KA4
MR-J3-DU45KA4
MR-J3-DU55KA4
