15 - 64
15. SERVO AMPLIFIERS WITH A LARGE CAPACITY
(
30k TO 55kW
)
(2) MR-J3-DU30KA4
MR-J3-DU37KA4
[Unit: mm]
2- 6Installation hole
240
Approx. 200
Approx. 200
328
128
180
Approx. 80
12060
6
219.2
TE2
TE3
TE1
For mounting
MR-J3BAT
TE2
TE1
PE
TE3
Approx. 60
Cooling fan
exhaust
Air intake
Terminal block layout
(Terminal cover removed)
Mass: 18[kg] (39.7[lb])
TE1
TE2
TE3
L
11
L
21
PE
Terminal block signal layout
Terminal block screw: M6
Tightening torque: 3.0 [N m]
(26.6 [lb in])
L
L
Terminal block screw: M4
Tightening torque: 1.2 [N m]
(10.6 [lb in])
Terminal block screw: M8
Tightening torque: 6.0 [N m]
(53.1 [lb in])
Terminal block screw: M8
Tightening torque: 6.0 [N m]
(53.1 [lb in])
Mounting screw
Screw size: M5
Tightening torque: 3.24 [N m]
(28.3 [lb in])
UVW
