13 - 26
13. COMMUNICATION FUNCTION
(2) Disabling/enabling the output devices (DO)
Transmit the following communication commands.
(a) Disable
Command Data No. Data
[9][0] [0][3] 1EA5
(b) Enable
Command Data No. Data
[9][0] [1][3] 1EA5
13.5.7 Input devices ON/OFF (test operation)
Each input devices can be turned on/off for test operation. when the device to be switched off exists in the
external input signal, also switch off that input signal.
Send command [9] [2], data No.[0] [0] and data.
Command Data No. Set data
[9][2] [0][0] See below
b31 b0
0: OFF
1: ON
b1
Command of each bit is transmitted to the slave
station as hexadecimal data.
bit Abbreviation bit Abbreviation bit Abbreviation bit Abbreviation
0 SON 8 SP1 16 24
1 LSP 9 SP2 17 25
2 LSN 10 SP3 18 26
3 TL 11 ST1 19 27 CDP
4 TL1 12 ST2 20 STAB2 28
5 PC 13 CM1 21 29
6 RES 14 CM2 22 30
7 CR 15 LOP 23 31
