12. OPTIONS AND AUXILIARY EQUIPMENT
(5) Crimping terminals for P and N terminals of servo amplifier
(a) Recommended crimping terminals
POINT
Always use recommended crimping terminals or equivalent since some crimping
terminals cannot be installed depending on the size.
Servo amplifier Brake unit
Number of
connected
units
Crimping terminal (Manufacturer)
(Note 1)
Applicable
tool
200V MR-J3-500A FR-BU2-15K 1 FVD5.5-S4 (Japan Solderless Terminals) c
class 2 8-4NS (Japan Solderless Terminals)
(Note 2)
d
FR-BU2-30K 1 FVD5.5-S4 (Japan Solderless Terminals) c
MR-J3-700A FR-BU2-15K 2 8-4NS (Japan Solderless Terminals)
(Note 2)
d
FR-BU2-30K 1 FVD5.5-S4 (Japan Solderless Terminals) c
MR-J3-11KA FR-BU2-15K 2 FVD8-6 (Japan Solderless Terminals) a
FR-BU2-30K 1 FVD5.5-6 (Japan Solderless Terminals) c
FR-BU2-55K 1 FVD14-6 (Japan Solderless Terminals) b
MR-J3-15KA FR-BU2-15K 2 FVD8-6 (Japan Solderless Terminals) a
FR-BU2-30K 1 FVD5.5-6 (Japan Solderless Terminals) c
FR-BU2-55K 1 FVD14-6 (Japan Solderless Terminals) b
MR-J3-22KA FR-BU2-55K 1 FVD14-8 (Japan Solderless Terminals) b
400V MR-J3-500A4 FR-BU2-H30K 1 FVD5.5-S4 (Japan Solderless Terminals) c
class MR-J3-700A4 FR-BU2-H30K 1 FVD5.5-S4 (Japan Solderless Terminals) c
MR-J3-11KA4 FR-BU2-H30K 1 FVD5.5-6 (Japan Solderless Terminals) c
FR-BU2-H55K 1 FVD5.5-6 (Japan Solderless Terminals) c
MR-J3-15KA4 FR-BU2-H55K 1 FVD5.5-6 (Japan Solderless Terminals) c
MR-J3-22KA4 FR-BU2-H55K 1 FVD5.5-8 (Japan Solderless Terminals) c
FR-BU2-H75K 1 FVD14-8 (Japan Solderless Terminals) b
Note 1. Symbols in the applicable tool field indicate applicable tools in (5)(b) in this section.
2. Coat the crimping part with an insulation tube.
(b) Applicable tool
Symbol
Servo amplifier side crimping terminals
Crimping
terminal
Applicable tool
Manufacturer
Body Head Dice
a FVD8-6 YF-1 E-4 YNE-38 DH-111 DH121
Japan Solderless
Terminals
b
FVD14-6
FVD14-8
YF-1 E-4 YNE-38 DH-112 DH122
c
FDV5.5-S4
FDV5.5-6
YNT-1210S
d 8-4NS YHT-8S
