6. DISPLAY AND OPERATION SECTIONS
Name Symbol Unit Description
Display
range
Peak load ratio b The maximum current is displayed.
The highest value in the past 15 seconds is displayed relative to the rated
current of 100
.
0
to
400
Instantaneous torque T Torque that occurred instantaneously is displayed.
The value of the torque that occurred is displayed in real time relative to
the rate torque of 100
.
0
to
400
Within one-revolution
position low
Cy1 pulse Position within one revolution is displayed in encoder pulses.
The value returns to 0 when it exceeds the maximum number of pulses.
However, the counter shows only the lower five digits of the actual value
since the servo amplifier display is five digits.
The value is incremented in the CCW direction of rotation.
0
to
99999
Within one-revolution
position high
Cy2 100
pulse
The within one-revolution position is displayed in 100 pulse increments of
the encoder.
The value returns to 0 when it exceeds the maximum number of pulses.
The value is incremented in the CCW direction of rotation.
0
to
2621
ABS counter LS rev Travel value from the home position in the absolute position detection
systems is displayed in terms of the absolute position detectors counter
value.
32768
to
32767
Load inertia moment
ratio
dC Multiplier
(
10
-1
)
The estimated ratio of the load inertia moment to the servo motor shaft
inertia moment is displayed.
0.0
to
300.0
Bus voltage Pn V The voltage (across P -N ) of the main circuit converter is displayed. 0
to
900
6.3.4 Changing the status display screen
The status display item of the servo amplifier display shown at power-on can be changed by changing the
parameter No.PC36 settings.
The item displayed in the initial status changes with the control mode as follows.
Control mode Status display at power-on
Position Cumulative feedback pulses
Position/speed Cumulative feedback pulses/servo motor speed
Speed Servo motor speed
Speed/torque Servo motor speed/analog torque command voltage
Torque Analog torque command voltage
Torque/position Analog torque command voltage/cumulative feedback pulses
