1. FUNCTIONS AND CONFIGURATION
Note 1. 0.3A is the value applicable when all I/O signals are used. The current capacity can be decreased by reducing the number of
I/O points.
2. When closely mounting the servo amplifier of 3.5kW or less, operate them at the ambient temperatures of 0 to 45
or at 75%
or smaller effective load ratio.
3. When a UL/C-UL-compliant servo motor is used in combination, the value is 2.9A.
4. Use an external dynamic brake for this servo amplifier. Failure to do so will cause an accident because the servo motor does
not stop immediately but coasts at an emergency stop and such conditions. Ensure the safety in the entire system.
(2) 400V class
Servo amplifier
MR-J3-
Item
60A4 100A4 200A4 350A4 500A4 700A4 11KA4 15KA4 22KA4
Output
Rated voltage 3-phase 323VAC
Rated current [A] 1.5 2.8 5.4 8.6 14.0 17.0 32.0 41.0 63.0
Main circuit power
supply
Voltage, frequency 3-phase 380 to 480VAC, 50/60Hz
Rated current [A] 1.4 2.5 5.1 7.9 10.8 14.4 23.1 31.8 47.6
Permissible voltage fluctuation 3-phase 323 to 528VAC
Permissible frequency fluctuation Within 5%
Power supply capacity Refer to section 11.2
Inrush current Refer to section 11.5
Control circuit
power supply
Voltage, frequency 1-phase 380 to 480VAC, 50/60Hz
Rated current [A] 0.1 0.2
Permissible voltage
fluctuation
1-phase 323 to 528VAC
Permissible frequency
fluctuation
Within
5%
Power
consumption [W]
30 45
Inrush current Refer to section 11.5
Interface power
supply
Voltage 24VDC
10%
Power supply capacity (Note 1) 0.3A
Control System Sine-wave PWM control, current control system
Dynamic brake Built-in External option (Note 2)
Protective functions
Overcurrent shut-off, regenerative overvoltage shut-off, overload shut-off (electronic thermal
relay), servo motor overheat protection, encoder error protection, regenerative error protection,
undervoltage, instantaneous power failure protection, overspeed protection, excessive error
protection
Position control
mode
Max. input pulse frequency 1Mpps (for differential receiver), 200kpps (for open collector)
Command pulse multiplying factor Electronic gear A:1 to 1048576
,
B:1 to 1048576, 1/10 A/B 2000
In-position range setting 0 to 10000 pulse (command pulse unit)
Error excessive 3 revolutions
Torque limit Set by parameter setting or external analog input (0 to 10VDC/maximum torque)
Speed control
mode
Speed control range Analog speed command 1: 2000, internal speed command 1: 5000
Analog speed command input 0 to 10VDC / Rated speed
Speed fluctuation ratio
0.01 or less (load fluctuation 0 to 100 )
0
(power fluctuation 10 )
0.2 or less (ambient temperature 25 10
(59
to
95 )
)
when using analog speed command
Torque limit Set by parameter setting or external analog input (0 to 10VDC/maximum torque)
Torque
control
mode
Analog torque command input 0 to
8VDC / Maximum torque (input impedance 10 to 12k )
Speed limit Set by parameter setting or external analog input (0 to 10VDC/Rated speed)
Compliance to standards
CE (LVD: IEC/EN 50178, EMC: IEC/EN 61800-3)
UL (UL 508C)
Structure
Natural-cooling,
open
(IP rating: IP00)
Force-cooling, open (IP rating: IP00)
Environmental conditions
Ambient
temperature
In operation
[
] 0 to 55 (non-freezing)
[ ] 32 to 131 (non-freezing)
In storage
[
] 20 to 65 (non-freezing)
[ ] 4 to 149 (non-freezing)
Ambient
humidity
In operation
90
RH or less (non-condensing)
In storage
Ambient
Indoors (no direct sunlight),
Free from corrosive gas, flammable gas, oil mist, dust and dirt
Altitude Max. 1000m above sea level
Vibration 5.9m/s
2
or less at 10 to 55Hz (directions of X, Y and Z axes)
Mass
[kg] 1.7 1.7 2.1 4.6 4.6 6.2 18 18 19
[lb] 3.75 3.75 4.63 10.1 10.1 13.7 39.7 39.7 41.9
Note 1. 0.3A is the value applicable when all I/O signals are used. The current capacity can be decreased by reducing the number of
I/O points.
2. Use an external dynamic brake for this servo amplifier. Failure to do so will cause an accident because the servo motor does
not stop immediately but coasts at an emergency stop and such conditions. Ensure the safety in the entire system.
