Appendix C. Record Formats 583
1st ed., 6/30/04 - 312579601
‘R’
(D9) CHAR CONST VOLMEDTR (X’D9’) STK1R MEDIA
‘U’
(E4) CHAR CONST VOLMEDTU (X’E4’) STK1U CLEANING
CARTRIDGE “U”
‘W’
(E7) CHAR CONST VOLMEDTW (X’E7’) STK2W CLEANING
CARTRIDGE “W”
‘Z’
(E9) CHAR CONST VOLMEDTZ (X’E9’) ZCART MEDIA
2
(2) BITSTRING 1 VOLFLAG1 VOLUME FLAG BYTE 1
1... .... X’80’ VOLSCR 1... .... - VOLUME IS SCRATCH
.1.. .... X’40’ VOLSEL .1.. .... - VOLUME IS SELECTED
..1. .... X’20’ VOLEXLBL ..1. .... - VOLUME HAS
EXTERNAL LABEL
...1 .... X’10’ VOLEXRD ...1 .... - EXTERNAL LABEL IS
OCR READABLE
.... 1... X’08’ VOLINUSE .... 1... - THIS RECORD IS IN USE
.... ...1 X’01’ VOLNILIB .... ...1 - VOLUME NOT IN LIB.
3
(3) HEXSTRING 1 VOLOHID OWNING HOST ID
4
(4) SIGNED-FWORD 4 VOLSELCT VOLUME SELECTION COUNT
8
(8) CHARACTER 6 VOLSER VOLUME SERIAL NUMBER,
LEFT JUSTIFIED AND BLANK
FILLED.
14
(E) CHARACTER 14 VOLHMLOC HOME LOCATION
14
(E) CHARACTER 2 VOLHMACS READABLE HEXADECIMAL ACS
NUMBER WHERE THE VOLUME
RESIDES.
16
(10) CHARACTER 1 -RESERVED- ‘:’
17
(11) CHARACTER 2 VOLHMLSM READABLE HEXADECIMAL LSM
# IN VOLHMACS WHERE THE
VOLUME RESIDES
19
(13) CHARACTER 1 -RESERVED- ‘:’
20
(14) CHARACTER 2 VOLHMPNL DECIMAL NUMBER OF THE
PANEL WITHIN VOLHMLSM
WHERE THE VOLUME RESIDES.
22
(16) CHARACTER 1 -RESERVED- ‘:’
23
(17) CHARACTER 2 VOLHMROW DECIMAL NUMBER OF THE
ROW WITHIN VOLHMPNL
WHERE THE VOLUME RESIDES.
25
(19) CHARACTER 1 -RESERVED- ‘:’
Table 63. SLUVVDAT Record Format (Continued)
Dec Hex Type Length Label Description
