Appendix C. Record Formats 515
1st ed., 6/30/04 - 312579601
SLSSMF07
Table 40. SLSSMF07 Record Format
Dec Hex Type Length Label Description
DSECT: SLSSMF07 - HSC RECORD TYPE 7 MAPPING MACRO
FUNCTION:
MAPS THE SUBTYPE 7 SMF RECORD PRODUCED BY THE HSC. THIS IS
PRODUCED FOR EACH SUCCESSFUL MOVE INITIATED BY THE HSC.
THESE RECORDS WERE ORIGINALLY DESIGNED TO PROVIDE OUR FIELD AND MARKETING STAFFS
WITH STATISTICAL CARTRIDGE MOVEMENT, LMU TIMING, AND ROBOTICS TIMING INFORMATION.
THESE RECORDS REPORT MOVEMENT SOURCE, DESTINATION, LMU TIMES, AND ROBOTICS TIMES. THESE
RECORDS ALSO CONTAIN VALUABLE SYSTEM ID AND JOB INFORMATION.
USAGE TIPS:
TO FIND ENTER ACTIVITY WITH THE SLSSMF07 RECORDS:
• FIND ALL SLSSMF07 MOVE DETAIL RECORDS WITH A SOURCE IDENTIFIER (SMF07SRI) = “CAP”(SMF07SCP).
• YOU CAN DETERMINE THE LIBRARY CARTRIDGE MOVEMENT TYPE THAT INITIATED THE ENTER
BY CHECKING SMF07TYP.
TO FIND EJECT ACTIVITY WITHIN THE SLSSMF07 RECORDS:
• FIND ALL SLSSMF07 MOVE DETAIL RECORDS WITH A DESTINATION IDENTIFIER(SMF07DEI) =
“CAP”(SMF07TCP).
• YOU CAN DETERMINE THE LIBRARY CARTRIDGE MOVEMENT TYPE THAT INITIATED THE EJECT BY
CHECKING SMF07TYP.
0
(0) AREA 1 SLSSMF07 MOVE DETAIL SMF RECORD
SUBTYPE
THIS DSECT MAPS THE SUBTYPE 7 RECORD PRODUCED BY THE HSC FOR EACH SUCCESSFUL MOVE IF SUBTYPE
7 RECORDING IS ENABLED.
0
(0) BITSTRING 1 SMF07TYP TYPE OF RECORD
1... .... X’80’ SMF07MSS MOUNT SCRATCH
.1.. .... X’40’ SMF07MNS MOUNT NON-SCRATCH
..1. .... X’20’ SMF07DSS DISMOUNT SCRATCH
...1 .... X’10’ SMF07DNS DISMOUNT NON-SCRATCH
.... 1... X’08’ SMF07SWS SWAP
.... .1.. X’04’ SMF07MOV MOVE
.... ..1. X’02’ SMF07NTR ENTER
.... ...1 X’01’ SMF07EJT EJECT
1
(1) BITSTRING 1 SMF07RQS REQUESTOR IDENTIFIER
.... .... X’00’ SMF07UNK UNKNOWN
.... ...1 X’01’ SMF07HSC HSC INITIATED (E.G. AUTOMATIC
CLEANING OF A DRIVE)
.... ..1. X’02’ SMF07JOB JOB PROCESSING INITIATED
.... ..11 X’03’ SMF07UTL HSC UTILITY INITIATED
.... .1.. X’04’ SMF07PRG HSC PROGRAMMATIC INTERFACE
