Appendix C. Record Formats 571
1st ed., 6/30/04 - 312579601
SLUVCDAT
Table 59. SLUVCDAT Record Format
Dec Hex Type Length Label Description
SLUVCDAT - FLAT FILE STATIC CONFIGURATION DATA DSECT
FUNCTION:
DESCRIBES THE STATIC CONFIGURATION INFORMATION WHICH MAY BE GENERATED TO THE FLAT
FILE BY THE VOLUME REPORT UTILITY
0
(0) STRUCTURE SLUVCDAT
0
(0) CHARACTER 1 -RESERVED- RECORD TYPE (C’C’)
1
(1) CHARACTER 3 CFGCCPFX CLEANING CARTRIDGE PREFIX
4
(4) SIGNED-FWORD 4 CFGTOTXP TOTAL TRANSPORTS ALL LSMS
(FUTURE)
8
(8) CHARACTER 2 -RESERVED- ***RESERVED***
10
(A) CHARACTER 2 -RESERVED- ***RESERVED***
12
(C) SIGNED-HWORD 2 CFGNMACS TOTAL DEFINED ACSS
14
(E) SIGNED-HWORD 2 CFGTOTLS TOTAL DEFINED LSMS
16
(10) SIGNED-HWORD 2 CFGTOTCA TOTAL CAPS FOR ALL LSMS
18
(12) SIGNED-HWORD 2 CFGTOTDR TOTAL DRIVES IN ALL LSMS
20
(14) HEXSTRING 1 CFGSMFTY SMF RECORD TYPE
21
(15) CHARACTER 1 CFGCMDPF COMMAND PREFIX CHARACTER
22
(16) BITSTRING 1 CFGDDISP DELETE DISPOSITION
1... .... X’80’ CFGDDSCR 1... .... - SCRATCH
.1.. .... X’40’ CFGDDNSC .1.. .... - NON-SCRATCH
23
(17) BITSTRING 1 CFGFLAG1 FLAGS
1... .... X’80’ CFGLIBFX 1... .... - LIB. IS FIXED LOC.
.1.. .... X’40’ CFGDISVF .1.. .... - DISMOUNT VOL. FLOAT
..1. .... X’20’ CFGCHKEP ..1. .... - CHECK EJECT PASSWORD
24
(18) BITSTRING 1 CFGLANG LANGUAGE TYPE
1... .... X’80’ CFGENGLS 1... .... - ENGLISH
.1.. .... X’40’ CFGITALN .1.. .... - ITALIAN
..1. .... X’20’ CFGGERMN ..1. .... - GERMAN
...1 .... X’10’ CFGFRNCH ...1 .... - FRENCH
25 (19)
BITSTRING 1 CFGSCRLB SCRATCH LABEL TYPE
.... .... X’00’ CFGSCRSL .... .... - SL (STANDARD)
