GFK-0825F Chapter 5 Station Configuration 5-27
5
Module Fault Reporting
On the next screen, configure whether or not the Bus Interface Unit will report faults from this
module to the network controller.
S1 Report Faults
< > tgl entr
YES
1. If you want to change the current selection, press F3 (tgl).
2. Use the F4 (entr) key to save the entry. Press F2 ( > ) to return to the original slot configuration
screen.
Default Inputs or Hold Last State
Next, configure what type of data the Bus Interface Unit should provide to the network if it stops
receiving inputs from the module.
S1 Hld Lst State
< > tgl entr
NO
1. Select YES if the Bus Interface Unit should hold inputs in their last states and supply that data
to the network.
Select NO if the Bus Interface Unit should default all the module's inputs and supply that data
to the network instead. Note: This selection has no effect if the BIU itself fails.
2. Use the F4 (entr) key to save the selection.
