GFK-0825F Chapter 5 Station Configuration 5-25
5
Default Outputs or Hold Last State
After selecting the module's reference address, configure what type of data the Bus Interface Unit
should provide to the module if it stops receiving outputs from the network.
S1 Hld Lst State
< > tgl entr
NO
1. Select YES if the Bus Interface Unit should hold outputs in their last states and supply that
data to the module.
Select NO if the Bus Interface Unit should default all the module's outputs and supply that data
to the module instead. Note: This selection has no effect if the BIU itself fails.
2. Use the F4 (entr) key to save the selection.
If Hold Last State is set to NO, the following screen appears:
S1 Out Def Pt 01
< > tgl entr
0010000010010101
Number of the point
at the cursor location
3. On this screen, select a default state (1 or 0) for each output.
4. Use the cursor keys to select outputs. Use the F3 (toggle) key to change the state of the output
at the present cursor location.
5. Use the F4 (entr) key to save the selections.
Module Fault Reporting
On the next screen, configure whether or not the Bus Interface Unit will report faults from this
module to the network controller.
S1 Report Faults
< > tgl entr
YES
1. If you want to change the current selection, press F3 (tgl).
2. Use the F4 (entr) key to save the entry. Press F2 ( > ) to return to the original slot configuration
screen.
