5-36 Field Control™ Genius® Bus Interface Unit User’s Manual
–
October 1999 GFK-0825F
5
Default Outputs or Hold Last Values
After zooming in from the reference address screen, configure what type of data the Bus Interface
Unit should provide to the module if it stops receiving actual output data from the network
controller.
S1 Hld Lst State
< > tgl entr
NO
1. Select
YES
if the Bus Interface Unit should hold outputs in their last states and supply that
data to the module.
Select NO if the Bus Interface Unit should default all the module's outputs and supply that data
to the module instead.
Note:
This selection has no effect if the BIU itself fails.
2. Press F4 to save the selection.
3. Press F2 ( > ) to go to the next screen.
Output Default Values
If Hold Last State is set to NO, the following screen appears:
S1 Out Def Ch 01
< > entr
00000
1. Enter output default values from the HHM keypad. To enter a negative value, press the minus
key after entering the value.
2. Use the F1 ( < ) and F2 ( > ) keys to select channels.
3. Press F4 (entr) key to save the selection.
4. Press F2 ( > ) to go to the next screen.
