5-40 Field Control™ Genius® Bus Interface Unit User’s Manual
–
October 1999 GFK-0825F
5
Configure a 16-Point Grouped Analog Input Module
When you select “Read” from the empty slot HHM screen, this module screen appears:
S:4 ALG240 1.0
< > del zoom
Assign I/O References for the Modul
e
When you "zoom" into the module's slot, a screen like this appears:
Default data length
S:4 AI *AI:016
AI01307-01322
< > chg entr
Default BIU data type
Next available reference
This screen shows the default table and length, and the next available reference address in
that table for that reference parameter. The length is displayed in units that are
appropriate for that data type (AI and AQ are in words, Q and I are in bits). The asterisk
indicates that this reference has not yet been defined.
If the present selection is acceptable, press F4 (enter) to accept it. The asterisk will
disappear. If you prefer to change the BIU table mapping, length, or reference value, press
F3 (change).
S:4 AI AI
Select table
tgl entr
From this screen, you can display the other BIU data types by pressing F3 (toggle). Press
F4 (enter) when the desired data type is displayed.
S:4 AI AI:016
Select length
clr entr
If you want to enter a different length for the displayed data type, press F3 (clear) to clear
the length field. Enter the new length from the keypad. If you enter an invalid length, the
HHM prompts
:
BAD LENGTH ERR
S1 FILTERING
20MS
S1 LINE FREQ
60 HZ
S1: Q *Q016
Q00001-00016
S1 Module-> %I
DEFAULT ZERO
S1: I * I:088
I00001-00088
S1 Module-> %AI
DEFAULT ZERO
S1: ALG240: 1.1
F4
S1: AI *AI016
AI00001-00016
F4, F2
F4, F2
F4, F2
F2 F1
S1 Network->%Q
DEFAULT ZERO
F2
F1
F2
F1
F2 F1
F1
F2
S1 CH 1
ACTIVE
S1 CH1 DEF RNG
1
S1 CH1 SPAN L
04000
S1 CH1 ENG L
04000
S1 CH1 ENG H
20000
S1 CH1 AL H
20000
S1 CH1 SPAN H
20000
S1 CH1 AL L
04000
F1, F2 select
channels
F2
F1
F2 F1
F2
F1
F2 F1
F2
F1
F2 F1
F2
F1
F2
F1
Re
p
eat for other
channels
F2
S1 CH 1
CONFIG
F4 ZOOM
S1 LINE FREQ
60 HZ
F1
F2
