8. Getting started
Image 8-40
Selecting the correct Head Location
Note: Only one A utoAlignment Head loca tion head location is allowed for all Panel Marker positions to be de fined for a single
Acuras Multi-point position.
5. From the Select Projectors that makeup this Position sectio
n, select a projector for which Acuras Multi-point position has to be
defined.
Image 8-41
Selecting a projector
Note: For each projector only one Acuras Multi-point position can be defined.
Note: Make sure that the selected projector is av ailable in the Head Loc ation that you have selected.
6. From the Select Cam era, Spectrometer and Laser subsection select the following devices from the drop down lists
- spectrometer
- laser
R59770509 AUTOALIGNMENT HEAD GEN II 26/11/2013
67
