9. Dynacolor™ calibration
9. DYNACOLOR™ CA LIBRAT ION
About this section
By default each projector is calibrated in the factory in ideal conditions. This means that Dynacolor calibration (using the buttons
Measure or Start Color Alignment) is not required in the field, except for specific situations. Dynacolor calibration may only be
performed by Barco trained and qualified technicians.
Matching the color gamuts of multiple projectors, i.e. matching the Dynacolor sets (Optimize button) is normally performed during
the alignment of a system if a new Golden Alignment is to be saved.
Overview
• Dynacolor calibration
• Matching Dynacolor sets of multiple projectors
• Dynacolor calibration: Color alignment
• Undoing a color alignment
9.1 Dynacolor calibration
Dynacolor calibration is performed for one projector at a time.
Make su re that Acuras position(s) has been defined for the selected p rojector prior to performing Dyn acolor
calibration.
If SIM 5W is used in combination with Acu ras, it is required that Dynacolor measured values were m easured
using the AutoAlignment Head. This means they should be measured from the DynaColor page in the XDS
RACU user in terface using the Measure button.
How to calibrate Dynacolor?
1. Select the projector to be calibrated.
2. Check the D ynacolor Active checkbox. See image 9-1.
3. Select the active Dynacolor set of that projector from the drop down list.
Note: A warning message is displayed if the s elected set is not active.
The x and y coordinates and L values of the selected active set are updated in the corresponding sections of Measured values
and Desired values automatically.
4. Check the Pause unselected projectors of group checkbox to pause all the unselected projectors. See image 9-1.
5. Press Measured.
R59770509 AUTOALIGNMENT HEAD GEN II 26/11/2013
107
