7. Installation
B
C
D
A
Image 7-15
Connecting SFTP Cat.5e cable to LEX unit
A SFTP Cat.5e cable
B AutoAlignment Head
CLEXUnit
D RJ 45 connector lid close
2. Open the lid and connect the other end of the supplied SFTP Cat.5e cable to the AutoAlignment Head.
B
A
C
D
Image 7-16
Connecting SFTP Cat.5e cable to LEX unit
A SFTP Cat.5e cable
B AutoAlignment Head
CLEXUnit
D RJ 45 connector lid open
7.2.5 Connection diagram
Diagram
A
C
D
TOP
TOP
E
B
F
Image 7-17
Connection diagram
A SFTP Cat 5e cable
B AutoAlignmen
t Head
CLEXUnit
DMCU
E Power to the XDS RACU MCU from the mains power supply (wall outlet)
FPowertot
he AutoAlignment Head from the mains power supply (wall outlet)
