334 Flow Rate Summary Charts
Flow rate summary charts Reference, Installation, and Operations Manual
June 2013 3-9000-743 Rev S
t of Engineering Drawings
Flow Rates (MMSCMD) Based Upon 30 m/s
kPag4 6 8 10121620243036
1000 0.232 0.528 0.915 1.442 2.046 3.231 5.082 7.350 11.869 17.091
1500 0.341 0.776 1.344 2.119 3.007 4.748 7.468 10.801 17.441 25.116
2000 0.453 1.029 1.783 2.810 3.989 6.297 9.904 14.325 23.133 33.311
2500 0.566 1.288 2.231 3.516 4.991 7.879 12.393 17.924 28.946 41.682
3000 0.682 1.552 2.688 4.237 6.014 9.495 14.935 21.600 34.882 50.230
3500 0.801 1.821 3.155 4.973 7.059 11.145 17.530 25.354 40.943 58.958
4000 0.922 2.097 3.632 5.725 8.126 12.830 20.179 29.186 47.131 67.869
4500 1.045 2.378 4.119 6.492 9.215 14.549 22.883 33.097 53.447 76.963
5000 1.171 2.664 4.615 7.275 10.326 16.302 25.641 37.086 59.889 86.240
5500 1.300 2.957 5.121 8.072 11.459 18.091 28.454 41.154 66.458 95.699
6000 1.431 3.254 5.637 8.885 12.612 19.912 31.319 45.298 73.150 105.336
6500 1.564 3.557 6.162 9.713 13.787 21.767 34.236 49.517 79.964 115.148
7000 1.700 3.866 6.696 10.555 14.982 23.653 37.203 53.808 86.893 125.126
7500 1.837 4.179 7.239 11.410 16.196 25.570 40.218 58.168 93.934 135.265
8000 1.977 4.497 7.789 12.278 17.428 27.515 43.277 62.592 101.078 145.553
8500 2.119 4.819 8.347 13.157 18.676 29.485 46.376 67.075 108.318 155.978
9000 2.262 5.145 8.912 14.047 19.939 31.479 49.512 71.611 115.642 166.524
9500 2.407 5.474 9.482 14.945 21.214 33.492 52.679 76.191 123.038 177.175
10000 2.553 5.805 10.056 15.851 22.500 35.522 55.871 80.808 130.494 187.911
