Reference Manual
300530EN, Rev BA
September 2012
5-5
Rosemount 2410
Section 5. Operation
5.4 ERROR MESSAGES In addition to presenting measurement values, the display can show software
and hardware error messages. In case of an error, the upper row shows
“ERROR” and the lower row toggles between “FAIL” and the error code.
Figure 5-2. Error codes can be
presented on the 2410 display
The following error codes are used:
Table 5-3. List of error codes
and messages that may appear
on the display
See “Error Messages” on page 6-26 for more information.
Fail/Error code
“ERROR” indication
Code Error
RAM Ram Failure
FPROM FPROM
HREG Holding register error
OMEM Other memory error
SYS System error
DPLY Display error
AUX AUX
FF ST FF stack
TBUS Tank Bus
HOST C Host
D MNGR Data manager
CFG Invalid Configuration
SW Software
