Reference Manual
300530EN, Rev BA
September 2012
Rosemount 2410
B-4
Appendix B. Product Certifications
HART/4-20 mA ENTITY IS I/O Option
Active Current Loop
XP-AIS CL I, DIV. 1 GP C & D
AEx de[ia IIC] IIB
U
o
= 23.1 V, I
o
= 95.3 mA, P
o
= 550 mW
Group IIC: C
o
0.14 F, L
o
3.9 mH
Group C, IIB: C
o
1.0 F, L
o
15 mH
Group D, IIA: C
o
3.67 F, L
o
33 mH
Passive Current Loop
AEx de[ib IIC] IIB
U
i
= 30.0 V, I
i
= 300 mA, C
i
= 0 F, L
i
= 0 mH
Ambient Temperature Limits: -50 °C to +70 °C
Temperature Code T4
Install per Control Drawing 9240040-901
