Reference Manual
300530EN, Rev BA
September 2012
Rosemount 2410
A-6
Appendix A. Reference Data
Code (Pos 8) Integral Display Note
1 LCD
0 None
Code (Pos 9) Power Supply Note
P Extended input range: 48-240 VAC at 50/60 Hz, and 24-48 VDC
Code (Pos 10) Software Note
S Standard
Code (Pos 11) Hazardous Location Certification Note
E1 ATEX Flameproof with intrinsically safe output
E5 FM-US Explosionproof with intrinsically safe output
E6 FM-Canada Explosionproof with intrinsically safe output
E7 IECEx Flameproof with intrinsically safe output
K1 ATEX Flameproof + FM-US Explosionproof
K3 ATEX Flameproof + IECEx Flameproof
K4 FM-US Explosionproof + FM-Canada Explosionproof
NA No hazardous location certification
Code (Pos 12) Custody Transfer Type Approval Note
R OIML R85 E
(7)
2008 performance certification
0 None
Code (Pos 13) Housing Note
A Standard enclosure Polyurethane-covered aluminium. IP 66/67
Code (Pos 14) Cable/Conduit Connections Note
1 ½–14 NPT and ¾-14 NPT Female thread. Includes 3 plugs
2 M20 x1.5 and M25x1.5 adapters Female thread. Includes 3 plugs, and 3 adapters
G Metal cable glands (½-14 and ¾-14 NPT) Min. temperature -20 ˚C (-4 ˚F). ATEX / IECEx
Exe approved. Includes 3 plugs, and 3 glands
E Eurofast male, ½–14 NPT and ¾-14 NPT Includes 3 plugs
M Minifast male, ½–14 NPT and ¾-14 NPT Includes 3 plugs
Code (Pos 15) Mechanical Installation Note
P Mounting kit for both wall and pipe installation 1-2 in. vertical or horizontal pipes
W Mounting kit for wall installation
0 None
Code Options – none or multiple selections are possible Note
QT IEC 61508 certificate and FMEDA-data
(8)
ST Engraved SST tag plate
Model Code Example: 2410 - S F R 0 3 2 1 P S E1 R A 1 P - ST
(1) Requires Secondary Fieldbus (Pos 5), code A-F, W, 0, 6-9.
(2) Requires Primary Fieldbus (Pos 4) code R or 4.
(3) Requires a separate Smart Wireless THUM™ Adapter (not included). Maximum Tankbus (FF) current is reduced to 200 mA.
(4) Requires Relay Output (Pos 6) code 0 or F.
(5) Requires Secondary Fieldbus (Pos 5), code 0 or Primary Fieldbus (Pos 4) code 4 and Secondary Fieldbus (Pos 5) code W, C, D, 8 or 9.
(6) Requires Secondary Fieldbus (Pos 5), code 0 or F.
(7) Requires a Rosemount 5900S gauge with the corresponding custody transfer approval. A Rosemount 2230 display or TankMaster is required for an
approved read-out.
(8) Requires Relay Output (Pos 6) code 2 or 3 (SIL 3 or SIL 2).
