Reference Manual
300530EN, Rev BA
September 2012
C-17
Rosemount 2410
Appendix C. Advanced Configuration
C.8 ARITHMETIC
OPERATIONS
The Rosemount 2410 Tank Hub supports various arithmetic calculations.
Holding Registers 4800 to 4879 are used for up to 10 arithmetic operations.
You may perform several operations for one or many tanks.
Arithmetic operations can, for example, be used to calculate the difference
between product levels measured by two different level gauges.
Figure C-12. Rosemount 2410
Holding registers for arithmetic
operations
Name Holding Register no. Description
Arithmetic1 operation 4800 Arithmetic operation to perform
0: None
1: Subtraction
2: Addition
3: Multiplication
4: Division
Arithmetic1 miscellaneous
configuration
4801 Ignore Source Unit
Arithmetic1 TMV type
destination
4802 Tank measurement variable in which the result is stored.
56: TMV Delta Level
60: TMV User Defined 1
61: TMV User Defined 2
62: TMV User Defined 3
63: TMV User Defined 4
64: TMV User Defined 5
Arithmetic1 tank number
destination
4803 Tank in which the result is stored.
0: Not active
1: Tank 1
2: Tank 2
3: Tank 3
4: Tank 4
5: Tank 5
6: Tank 6
7: Tank 7
8: Tank 8
9: Tank 9
10: Tank 10
Arithmetic1 A TMV Type 4804 Tank measurement variable type for the arithmetic
operation parameter A
Arithmetic1 A tank number 4805 Tank for the arithmetic operation parameter A.
0: Not active
1: Tank 1
2: Tank 2
3: Tank 3
4: Tank 4
5: Tank 5
6: Tank 6
7: Tank 7
8: Tank 8
9: Tank 9
10: Tank 10
Arithmetic1 B TMV Type 4806 Tank measurement variable type for the arithmetic
operation parameter B
