Reference Manual
300530EN, Rev BA
September 2012
Rosemount 2410
www.rosemount-tg.com
Appendix A Reference Data
A.1 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page A-1
A.2 Dimensional drawings . . . . . . . . . . . . . . . . . . . . . . . page A-4
A.3 Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . page A-5
A.1 SPECIFICATIONS
General
Product Rosemount 2410 Tank Hub
Single tank version • Supports one 5900S 2-in-1 gauge or two radar level gauges, type 5300, 5400, or 5900S
• Total Observed Volume (TOV) calculation with 100-point strapping table
Multiple tank version For a 5300/5400/5900S system configuration:
• The software supports 16 field devices and 10 tanks per hub
• Maximum five gauges, type 5300 or 5400 per hub
The actual number of tanks/instruments a hub supports depends on the configuration, which
types of units are connected and how many. See “Power Budget” on page 3-7.
• Hybrid calculations (mass and density) for up to three tanks
• Total Observed Volume (TOV) calculation with 100-point strapping table for one tank
Examples of connected field devices Radar Level Gauges (type 5900S
(1)
, 5300, and 5400), Rosemount 2240S Multi-input
Temperature Transmitter, Rosemount 644 Temperature Transmitter, Temperature / Water
Level Sensors, Rosemount 3051S Scalable Pressure Transmitter, Rosemount 2230
Graphical Display
Start-up time Less than 30 s
Legal custody transfer type approval OIML R85:2008, and national certifications such as PTB, NMi etc
Hazardous location certifications ATEX, FM-C, FM-US, IECEx, and national certifications. For details, see “Appendix B:
Product Certifications” and “Ordering Information” on page A-5.
Safety/overfill SIL 2 and SIL 3 certified.
TÜV tested and WHG approved for overfill prevention. For national approvals, consult your
local Rosemount Tank Gauging representative
CE-mark Complies with applicable EU directives (EMC, ATEX)
Ordinary location certification Complies with FM 3810:2005 and CSA: C22.2 No. 1010.1
Communication / Display / Configuration
Tankbus The intrinsically safe side of the Rosemount 2410 connects to the Tankbus which
communicates with field devices on the tank using F
OUNDATION™ fieldbus
Fieldbus Primary fieldbus: Rosemount 2410 communicates with a host or a field communication unit
via TRL2 Modbus, RS485 Modbus, Enraf or HART
Secondary fieldbus
(2)
: TRL2 Modbus, Enraf (other options available soon), WirelessHART
for Smart Wireless THUM™ Adapter
Relay outputs SIL safety relay output
(3)
: One SIL 2/SIL 3 certified relay is available for overfill prevention.
This non-intrinsically safe solid state relay is closed/energized during normal operation
Maximum voltage and current: 260 VAC/VDC, 80 mA
Relay outputs (Non-SIL): Maximum two relays, controlled by 10 independent virtual relay
functions which can be configured for different tanks and process variables.
The two non-intrinsically safe solid state relays are user configurable for normally energized
or de-energized operation.
Maximum voltage and current: 350 VAC/VDC, 80 mA
