Chapter 2 Front Panel Overview 63
Chapter 2
Nesting
Each level of password-protected menus (Administration and Service) includes
all options available in the subordinate menu. For example, all options
available in the
Administration Menu are also included in the Service Menu. This
functionality reduces the need to return to the
Main Menu or re-enter a
password. Figure 29 illustrates this “nesting” concept.
Figure 29 Nesting
Note The front panel defaults back to the home or logo screen after
approximately three minutes of inactivity, unless an error
message or confirmation message is displayed that needs to be
acknowledged.
Information Operations Administration Service
Library Information
Date and Time
View Configuration
Drive Information
Drive and Tape
Operations
Magazine Access
Mailslot Access
Information
Operations
Change
Configuration
Run Test
Online Drive Repair
Set Date and Time
Upgrade Drive
Firmware
Information
Operations
Change
Configuration
Run Test (with
additional capability)
Online Drive Repair
Set Date and Time
Upgrade Drive
Firmware
Firmware Revisions
Power Supplies
