174 Removing and Replacing a Cosmetic Door Chapter 5
Removing and Replacing a Cosmetic Door
Removing a Cosmetic Door Face
1. Pull the front door outward. Use the front panel display and/or key to
unlock the door.
2. Remove the front magazine by lifting the handle on the top of the
magazine and pulling upward.
3. Twist the release tab on the back of the cosmetic door and simultaneously
pull upward on the sheet-metal tab to release (see Figure 59 on page
175).
Caution To avoid breaking the tab, do not use excessive force.
Replacing a Cosmetic Door
1. Insert the cosmetic door’s connecting hooks through the holes in the front
of the door.
2. Holding the cosmetic door in place, align the holes in the sheet-metal with
the holes in the door front.
3. Push the sheet-metal tab downward so that the sheet-metal plate clicks into
place beneath the plastic tab.
4. Replace the magazine, and close the door.
