4 - 8
4.4.1 Monitoring a program
4 CREATING PROGRAM IN ST LANGUAGE
GX Works2
You can switch the programmable controller status between "RUN" and "STOP" using remote operation as
follows.
The Settings of the remote operation may vary depending on the programmable controller used.
Refer to the following manual for the details on the remote operation:
GX Works2 Version 1 Operating Manual (Common)
Select [Online] [Remote Operation] to display the Remote Operation screen. You can switch the
programmable controller status between "RUN" and "STOP" on this screen.
Monitor status display example
Operation
Allows you to select the
programmable controller
CPU status to be set.
Select either "RUN",
"PAUSE" or "STOP" for
this example.
Programmable
controller status
Displays the programmable
controller CPU status.
Connection Channel
List information
Displays the connection
target information
currently set.
Specify Execution
Target
Allows you to set the
target station for
remote operation.
Select "Currently
Specified Station" for
this example.
Operation during RUN
Allows you to set the
operations to be
executed to the device
memory and signal
flow when the
programmable
controller CPU is
switched to RUN.
Displays the OFF status.
Displays the ON status.
Displays the current values.
(To the next page)
