5 - 2 5 - 2
MELSEC-Q
5 PARAMETER SETTINGS
5
5.1.2 Parameters for the slave function
The following explains the setting items of the parameters for the slave function.
(1) Description of the parameter settings using the sequence program
The parameter settings using the sequence program include the following items:
1) Setting area of the number of slave function reception bytes
2) Setting area of the number of slave function transmission bytes
For the method and details of the parameter settings using the sequence
program, see Section 8.2, "Parameter Settings Using the Sequence Program",
and Section 3.4.2 (21), "Setting area of the number of slave function reception
bytes/setting area of the number of slave function transmission bytes".
5.1.3 Common parameters for the master/slave functions
The following explains the setting items of the common parameters for the
master/slave functions.
(1) Description of the parameter settings using the sequence program
The parameter settings using the sequence program include the following items:
1) Auto communication start settings
For the method and details of the parameter settings using the sequence
program, see Section 7.3.1, "Parameter settings using the sequence program",
Section 8.2, "Parameter settings using the sequence program", and section 3.4.2
(28), "auto communication start setting".
5.2 Setting Using the Sequence Program
For the method to set the parameters using the sequence program, see the following
sections:
• Section 3.3.2 (7) and (8), "Saving parameter to the flash ROM: X06, save
parameter to flash ROM completion: X07, save parameter to flash ROM request:
Y17"
• Section 3.4.2 (13), "Parameters for the master function"
• Section 3.4.2 (21), "Setting area of the number of slave function reception
bytes/setting area of the slave function transmission bytes"
• Section 7.3.1, "Parameter settings using the sequence program"
• Section 8.2, "Parameter Settings Using the Sequence Program"
