6 UTILITY PACKAGE (GX Configurator-DN)
6.4 Auto Refresh Settings
[Purpose of Setting]
Sets the QJ71DN91's buffer memory that is automatically refreshed.
For the auto refresh setting items, see Section 6.1.
Reading and writing with the sequence program will no longer be required by setting
auto refresh.
[Startup procedure]
"Start I/O No. " "Package name" "Module model name" Auto refresh
Enter the start I/O No. in hexadecimal.
[Setting screen]
POINT
The data set using GX Configurator-DN of Version 1.15R or later should not be
edited or written using GX Configurator-DN of Version 1.14Q or earlier.
Doing so will corrupt the set data.
If a numerical value has been entered accidentally, press Cancel
to interrupt.
