Ð 21 Ð
Important!
Fault Annunciation
Since the phone module, RF receiver(s), VIM and the polling loop are shared
among the 2 partitions, the scheme for annunciating their failure follows:
Respective faults (for zones 87, 88Ð91, 93 & 97) will report as trouble conditions
only, and as such, should be assigned either zone type 00 if no annunciation is
desired, or zone type 05 if annunciation as trouble condition is desired. If the
polling loop or RF link fails supervision, the corresponding zone number will
display a trouble condition for each partition that uses the device that failed. In
addition, all zones associated with that device will indicate a check condition. The
trouble condition will not interfere with the ability to arm the partition, but the faults
must first be bypassed.
Compatible Polling Loop
Devices
4208 Eight Zone Polling Loop Expansion Module
Does not support 2-wire smoke detectors.
Set DIP switches to identify 8 zones.
4190WH Two Zone Remote Point Module
The left zone can be EOLR supervised, if necessary, and can
accept either open or closed circuit sensors, and can be set for
fast response. The right zone is unsupervised and can accept
closed circuit sensors only.
4278 Quad Element Polling Loop PIR
DIP switch programmable and connects directly to the polling
loop. Features an auxiliary sensor loop that permits connection of
another nearby closed circuit alarm sensor (reed contact, etc.).
4275 Dual Element Polling Loop PIR
DIP switch programmable.
4194 Surface Mounted Reed Contact (Wide Gap)
DIP switch programmable.
4197/4297 Polling Loop Extender Module
By installing a 4297 at the end of the first loop, the polling loop
can be continued. If more than 64mA needs to be drawn from the
polling loop to power RPMs, use of the 4197/4297 provides
another loop with 64mA available. See instructions accompany-
ing unit.
4192SD Photoelectric Smoke Detector
DIP switch programmable.
4192SDT Photoelectric Smoke Detector w/Heat Detector
DIP switch programmable.
4192CP Ionization Smoke Detector
DIP switch programmable.
4139SN Auto Smart Surface Mount Reed Contact
Serial number ID "enrolled" by control panel.
Check product availability.
4191SN Auto Smart Recessed Reed Contact
Serial number ID "enrolled" by control panel.
Check product availability.
4939SN Auto Smart Surface Mount Contact
Serial number ID "enrolled" by control panel.
Check product availability.
4959SN Auto Smart Overhead Door Contact
Serial number ID "enrolled" by control panel.
Check product availability.
998MX Polling Loop PIR
Serial number ID "enrolled" by control panel.
