N5944-6ZZ 6/97
ADDENDUM TO:
VISTA-40 and VISTA 50P/UL Installation Instructions
NEW "QED" DEVICE ENROLLMENT PROCEDURE FOR 5800 SERIES
TRANSMITTERS AND SERIAL NUMBER POLLING LOOP DEVICES
This addendum describes the new procedure for "enrolling" 5800 series transmitters or serial number
polling-loop devices into the system. There are two methods of enrolling:
• Enrolling Through Zone Programming
• Enrolling Through Sequential Mode
The Enrolling Through Zone Programming procedure describes how to enroll each wireless transmitter or
serial number polling-loop devices into the system as you are entering the zone information. The
Enrolling Through Sequential Mode procedure describes how to enroll all the wireless transmitters and/or
polling-loop devices into the system
after all zone information has been entered
. Use these procedures
in place of the procedures described in the Installation Instructions.
As an option, the new enroll modes allow you to use a 5803 or 5804 button-type transmitter as a
"program tool." The program tool:
• is used for enrolling 5800 series RF wireless or serial number polling loop devices
• duplicates the ✱ and # key programming functions (left program tool button = ✱, right = #). You can
move to the physical location of the transmitter to be enrolled, press the upper left-hand button of the
program tool, and then trip the intended transmitter.
• can also be used as a transmitter in the system. If you plan to use an existing transmitter, it must first
be enrolled into the system as its associated zones. You may then program it as the tool.
An alpha keypad is required for the following procedures.
ENROLLING THROUGH ZONE PROGRAMMING (#93)
1. Enter Programming mode [Installer Code] + 8 + 0 + 0. Enter Zone
Programming by pressing #93. If the system has been set up to use
5800 series RF, and a program tool has already been entered, skip to
step 4. If no program tool has been entered, the following prompt will
appear:
PROGRAM TOOL?
0 = NO, 1 = YES 0
2. If a program tool is being used, enter "1." If not using a tool, enter "0" and
skip to Step 4.
10 INPUT S/N: L
Axxx-xxxx
3. If "1" is entered, the system will prompt for the unit’s serial number. Enter
the program tool’s serial number using one of the following methods:
a) Enter the 7 digit serial number for the transmitter
or
b) Press any button on the transmitter. The keypad should beep three
times and display the serial number of the tool.
10 PROG AS BR: 3
A123-4567 3
In this example, the serial number is A123-4567. Once enrolled, the
upper left-hand button of the program tool can be pressed to ready the
system for enrolling a transmitter into the system. Pressing the # key on
the keypad will cause the system to back up to the “PROGRAM TOOL ? “
prompt.
The serial number for the program tool will only remain in
the system until the programming mode is exited.
(Entering ✱97 will not delete the tool.)
Press [✱] to continue.
