Crestron CLS-C6RF iLux
™
Integrated Lighting System w/infiNET
™
Function name Toggle Scene (on, 1-15)
Behavior Alternates between “Recall Scene” and “Turn Off Scene Lights” actions
for the specified scene. In determining which action should be executed,
the CLS-C6RF will check the state of all lights programmed in the
scene. If any light in the scene is on, this function will cause the lights to
go off. If all lights in the scene are off, this function will recall the scene.
LED Flash while lights are actively fading (either direction). On when any
light in scene is on, while not fading.
Applies To Standard Rocker, Shifted Rocker, Remote Button
Rocker
Behavior
If the “Enable Raise/Lower on Scene Recall Buttons” option is set, then
the right and left rockers perform “Scene Raise” and “Scene Lower”
functions, whether or not scene feedback LED for that button is lit. To
toggle the scene, center of button must be pressed.
If the “Enable Raise/Lower on Scene Recall Buttons” option is not set,
then the right, left, and center press all do the same thing.
Notes Toggle function intended only for scenes that do not affect shades.
Function name Raise Lighting Load (1-6)
Behavior The specified lighting load will be raised as long as the button is held – it
will stop when button released. Rate is the global ramp rate.
If they hit the High End limit, the lights will stop at that point, but the
bargraph display will continue to rise. If going up from OFF, lights will
immediately go to the Low End limit, and the bargraph display will start
rising from 0. When the display (i.e.: the internal ramp value) reaches
the Low End limit, the light will start moving up in sync.
For non-dim load, lights will immediately go to full on.
LED On while button is pressed
Applies To Remote Button
Rocker
Behavior
N/A
Notes This is same as pressing the right side of front panel function button
when in Lights Mode.
Function name Lower Lighting Load (1-6)
Behavior Specified lighting load will be lowered as long as button is held – will
stop when button is released. Rate is the global ramp rate.
If loads hit the Low End limit, the bargraph will continue to go down, but
lights will stay at Low End limit level until reach OFF – at which point
they will turn off.
If starting from above the High End limit, the bargraph will start to go
down, but lights will stay at High End limit level until display reaches the
High End limit – then the light and bargraph will start moving in sync.
For non-dim load, lights will immediately go to full off.
LED On while button is pressed
Applies To Remote Button
Rocker
Behavior
N/A
Notes This is same as pressing the left side of front panel function button
when in Lights Mode.
Operations Guide - DOC. 6418A iLux
™
Integrated Lighting System w/infiNET
™
: CLS-C6RF • 49
