4. If you would like a certain lighting load to be unaffected by that scene
recall, press and hold the center of the button (so both sides make contact)
for three seconds. The top two and the bottom two LEDs of the associated
bargraph will be lit (and the display will show - -) to indicate that the level
of the lighting load will not change when that scene is recalled.
5. To change the shade presets for that scene press the Shades button; the
Shades LED will be lit.
6. Use the six function buttons to adjust the levels of the shade groups for that
scene. Press the right side to raise the shades; press the left side to lower
them. While the shades are moving, press any part of the button to stop.
Note that for shades that are not “presettable,” only full open or full closed
positions can be recalled as part of a scene.
7. If you would like a certain shade group to be unaffected by that scene recall,
press and hold the center of the button (so both side make contact) for three
seconds. The top two and the bottom two LEDs of the associated bargraph
will be lit (and the display will show - - ) to indicate that the level of that
shade group will not change when that scene is recalled.
8. To adjust the fade time, press the ^ and v buttons. When going up, the value
will go from 0 seconds to 59 seconds, and then 1 minute to 99 minutes.
When going down, the value will go from 99 minutes to 1 minute, and then
59 seconds to 0 seconds. The Min and Sec LEDs light as appropriate.
Adjustment to fade time can be made when either Lights mode or Shades
mode is active.
9. When all the lighting loads are at the desired level and shades are at the
desired position, press Save to save these settings as the new preset for that
scene. If you make a mistake while changing a setting, press Cancel to
discard changes and return to Standard mode before pressing Save.
10. Repeat the above procedures for all scenes that require changes.
Setup Mode
The Setup mode is used to change internal settings on the CLS-C6RF, including the
scene presets as discussed in the previous paragraph.
• To enter Setup mode
, press and hold the Save and Cancel buttons for five
seconds. The Cancel button LED will blink, and the first setup option (Sc) will
be displayed, to indicate that the unit is now in Setup mode.
Note that while scrolling through the list of setup options, before an option is
“locked”, the Save button is not functional and its LED is off. However, the
Cancel button LED will blink - since the button can be pressed to return the unit
to Standard mode.
• If the unit is connected to a Cresnet control system and you are in the process of
adjusting scene settings, you cannot enter Setup mode.
• When the unit is in Setup mode, the two-digit display uses a two-character
mnemonic to indicate which specific aspect of the CLS-C6RF you are changing.
As these are being adjusted, the display may indicate values. The following is a
list of the different Setup modes, and the corresponding mnemonic codes.
Operations Guide - DOC. 6418A iLux
™
Integrated Lighting System w/infiNET
™
: CLS-C6RF • 13
