Crestron CLS-C6RF iLux
™
Integrated Lighting System w/infiNET
™
Setup
Network Wiring
When wiring the network, consider the following:
• Use Crestron Certified Wire.
• Use Crestron power supplies for Crestron equipment.
• Provide sufficient power to the system.
CAUTION: Insufficient power can lead to unpredictable results or damage
to the equipment. Please use the Crestron Power Calculator to help calculate
how much power is needed for the system
(http://www.crestron.com/calculators
).
• For larger networks, Use a Cresnet Hub/Repeater (CNXHUB) to maintain
signal quality.
For more details, refer to “Check Network Wiring” on page 39.
Identity Code
The MNET ID of the CLS-C6RF has been factory set to 1F. After an infiNET device
is added to an infiNET network, its MNET ID must be changed to a value that can be
addressed by the control system program (03 to 20). The MNET IDs of multiple
CLS-C6RF devices in the same system must be unique. MNET IDs are changed
from a personal computer (PC) via the Crestron Toolbox™ or iLux Designer
software programs. (Refer to “Establishing Communication” on page 31)
When setting the MNET ID, consider the following:
• The MNET ID of each unit must match an ID code specified in the SIMPL
Windows or D3 Pro
™
/Crestron SystemBuilder
™
program..
• Each network device on the same gateway must have a unique MNET ID.
For more details, refer to the Crestron Toolbox or iLux Designer help files.
Installation
Detailed installation procedures are provided in the latest version of the Crestron
iLux Lighting Systems Installation Guide (Doc. 6416 for CLS-C6RF/C6MRF;
Doc. 6417 for CLSI-C6RF/C6MRF).
The figure on the following page illustrates five installation configurations and
includes brief descriptions of the rationale behind each one.
NOTE: The power usage requirements on the local devices network is different
from that described above. The CLS-C6RF provides 24VDC power for up to four
keypads and/or shade controllers on the local devices network. An additional power
supply is required to support more than four devices. Also, each C2N-SDC-DC
shade controller requires its own additional power supply.
Operations Guide - DOC. 6418A iLux
™
Integrated Lighting System w/infiNET
™
: CLS-C6RF • 9
