93
REPAIR PARTS - JACKET PANEL ASSEMBLY
Item
No.
Description
Boiler Sections / Quantity
Part No.
04 05 06 07 08 09 10 11 12 13 14 15 16 17 18
1 Jacket Front Panel
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 100753-01
2 Jacket Front Panel Wiring Harness Cover Plate
2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 101422-01
3
#8 x 2-1/2” Lg. Type AB, Slotted Hex Washer Head
Sheet Metal Screw, Steel, Plated
38 38 38 46 46 46 46 46 58 58 58 58 58 70 70 80860018
4A Jacket Left Rear Panel Assy. w/ Insulation
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 101709-01
4B Jacket Right Rear Panel Assy. w/ Insulation
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 101708-01
5 Jacket Blank Sensor J-Box Cover
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 101427-01
6 Jacket Outer Top Corner Panel Assembly with Short & Long Brackets:
6A. 27” Lg.
2 2 100765-01
6B. 33-3/4” Lg.
2 2 2 2 2 2 2 2 100765-02
6C. 40-1/2” Lg.
2 2 2 2 2 100765-03
7 Jacket Outer Top Intermediate Panel Assembly with Long Brackets:
7A. 27-1/16” Lg.
2 2 4 2 100764-01
7B. 33-13/16” Lg.
2 2 2 2 100764-02
8 Jacket Outer Top Corner Panel Assembly with Short Brackets:
8A. 6-11/116” Lg.
2 2 2 100763-01
8B. 27” Lg.
2 2 2 100763-02
8C. 33-3/4” Lg.
2 2 2 2 2 2 2 100763-03
8D. 40-1/2” Lg.
2 2 100763-04
9 Jacket Front Top Panels:
9A. 22-5/16” Lg.
1 1 1 100736-01
9B. 29-1/16” Lg.
1 1 1 1 1 1 1 100736-02
9C. 35-13/16” Lg.
1 1 1 1 1 100736-03
10 Jacket Intermediate Top Panels:
10A. 20-5/16” Lg.
1 1 100737-01
10B. 27-1/16” Lg.
1 1 1 2 2 3 3 100737-02
10C. 33-13/16” Lg.
1 1 2 2 100737-03
