SECTION VII - BURNER SPECIFICATIONS
BOILER
MODEL
BURNER
MIN.
INPUT
(GPH)
BURNER
MAX.
INPUT
(GPH)
BURNER
MODEL
AIR
TUBE
COMB.
BURNER SETTINGS
PUMP
PRESSURE
(PSI)
NOZZLE
MAKE
NOZZLE
DATA
HEAD
LOW FIRE
AIR OR
SHUTTER
HIGH FIRE
AIR OR
BAND
LOW
FIRE
HIGH
FIRE
GPH X
ANGLE
- TYPE
MPC4 1.75 3.55 CF500 CF60KK 3 10 2 N/A 150 Delavan 2.75 X 70 - B
MPC5 3.0 5.5 CF800 CF60KH 3 8.5 0 N/A 150 Delavan 4.50 X 70 - B
MPC6 4.0 7.1 CF1400 CF66KD 4 43 48 150 250 Delavan 4.50 X 60 - B
MPC7 4.0 8.7 CF1400 CF66KE 6 45 51 150 300 Delavan 5.00 X 45 - B
MPC8 7.0 10.2 CF2300 CF66KG 1 37 47 150 300 Delavan 6.00 X 45 - B
MPC9 7.0 11.8 CF2300 CF66KG 7 39 41 150 295 Hago 7.00 X 45 - P
MPC10 7.0 13.4 CF2300 CF66KG 9 43 54 140 280 Delavan 8.00 X 45 - B
MPC11 10.0 15.0 CF2500 CF66KP 2 22 35 275 275 Hago 4.50 X 45 - P
MPC12 10.0 16.6 CF2500 CF66KP 2 23 41 300 300 Hago 5.00 X 45 - P
MPC13 10.0 18.2 CF2500 CF66KP 5 24 38 300 300 Hago 5.50 X 45 - P
MPC14 10.0 19.8 CF2500 CF66KP 6 26 43 275 275 Hago 6.00 X 45 - P
MPC15 10.0 21.5 CF2500 CF66KP 9 25 40 270 270 Hago 6.50 X 45 - P
MPC16 17.0 23.0 CF3500 CF114KR 7 29 42 275 275 Hago 7.00 X 45 - P
MPC17 17.0 24.5 CF3500 CF114KR 8 30 51 275 295 Hago 7.50 X 45 - P
MPC18 17.0 26.0 CF3500 CF114KR 8 29 68 265 265 Hago 8.00 X 45 - P
Table XIIIa: Beckett #2 Oil Burner Specications
BOILER
MODEL
BURNER
MIN.
INPUT
(MBH)
BURNER
MAX.
INPUT
(MBH)
BURNER
MODEL
DAMPER SETTINGS
MANIFOLD PRESSURE
(“WC)
MINIMUM
INLET
PRESSURE
(“WC)
LOW
FIRE
HIGH
FIRE
SHUTTER BAND
LOW FIRE
(START)
HIGH
FIRE
MPC4 300 500 CG10.3 N/A N/A 6 0 1.0 1.8 2.80
MPC5 300 773 CG10.5 N/A N/A 10 0 1.6 3.2 4.80
MPC6 350 995 CG15.2 26 45 N/A N/A 1.15 3.15 4.30
MPC7 350 1216 CG15.3 29 66 N/A N/A 1.1 3.5 4.60
MPC8 550 1438 CG25.1 16 45 N/A N/A 1.1 3.6 4.70
MPC9 550 1660 CG25.2 22 53 N/A N/A 0.8 3.57 4.37
MPC10 550 1881 CG25.3 25 54 N/A N/A 0.75 3.4 4.15
MPC11 550 2103 CG25.4 27 52 N/A N/A 0.9 3.6 4.50
MPC12 730 2325 CG50.1 28 72 N/A N/A 0.9 4.2 5.10
MPC13 730 2547 CG50.2 20 39 N/A N/A 0.8 3.6 4.40
MPC14 730 2769 CG50.3 22 39 N/A N/A 0.7 3.4 4.10
MPC15 730 2991 CG50.3 22 44 N/A N/A 0.65 4.0 4.65
MPC16 730 3213 CG50.3 21 46 N/A N/A 0.6 4.3 4.90
MPC17 730 3435 CG50.4 24 47 N/A N/A 0.7 4.0 4.70
MPC18 730 3657 CG50.4 25 72 N/A N/A 0.7 4.9 5.60
Table XIIIb: Beckett Gas Burner Specications
NOTICE
MPC boiler ratings and capacities are based upon the following burners, pump pressures, nozzle sizes and
manifold pressures. Refer to instructions furnished with burner for additional information regarding proper
installation, fuel piping, wiring details, burner adjustments, service instructions and burner start-up.
