76
The TIME that was entered before
setting an on or off time to NEVER
is saved, and will re-appear when a
day is set in place of NEVER.
Setting both the DIAL OUT 1 ON
and the DIAL OUT 1 OFF times to
NEVER will make DIAL OUT NUMBER 1
never active.
DIAL OUT NUMBER 2
DIAL OUT 2 ON
DIAL OUT 2 OFF
DIAL OUT NUMBER 2 can entered
into the system and set for time
and dates exactly like DIAL OUT
NUMBER 1.
The default for DIAL OUT 2 ON is
12:00 AM MTWTFSS, and the default
for DIAL OUT 2 OFF is NEVER, so
that DIAL OUT NUMBER 2 is always
active.
DIAL OUT NUMBER 3
DIAL OUT 3 ON
DIAL OUT 3 OFF
Same as DIAL OUT NUMBER 2.
DIAL OUT NUMBER 4
DIAL OUT 4 ON
DIAL OUT 4 OFF
Same as DIAL OUT NUMBER 2.
10. UNDERWRITER'S
LABORATORIES
REQUIREMENTS
The Model 1503 Version 2, Model
1503-LC, Model 1102 Expansion En-
closure and Model 1503A2005 con-
soles have been tested and Listed
by UL for these applications:
- UL 985, Household Fire Warning
System Units
- UL 1023, Household Burglar Alarm
System Units
- UL 1635, Digital Burglar Alarm
Communicator System Units
- UL 1637, Home Health Care Sig-
naling Equipment
When used in a UL Listed Instal-
lation, the following items apply:
1. The “High Security Mode” must
be ON.
2. The “Enable Auto Bypass” fea-
ture must be OFF.
3. The ENTRY DELAY shall not
exceed 45 seconds.
4. The EXIT DELAY shall not ex-
ceed 60 seconds.
5. Double Delay and Quad Delay
zone types shall not be used.
6. Underwriter's Laboratories
requires the sounding device to
be mounted indoors. If, however,
the sounding device is connected
to the "EXT HORN" terminals of
the Model 1503, then the OUTSIDE
SIREN DELAY shall be set to 0.
