Home Automation, Inc.
18
If you are having your system
monitored by a central station, the
central station will be sent a code
representing the type of alarm
(medical emergency button.)
If you are not using central
station monitoring but are using
the voice dial out capability, the
system looks at the MEDICAL DIAL
ORDER to determine which number to
call first, and calls that number.
If you are using both central
station monitoring and voice dial
out, then the voice dial out is
delayed by five minutes to give the
central station time to call you
back.
The message delivered to the
called party when he answers and
says anything is: “MEDICAL EMER-
GENCY ALARM (your address here
*
)
...EMERGENCY ...EMERGENCY... THE
MEDICAL EMERGENCY ALARM HAS BEEN
ACTIVATED AT THE FOLLOWING ADDRESS:
(Your address is spoken here
*
)
PHONE NUMBER (your phone number
that is stored in SET-UP location
MY PHONE NUMBER is spoken here)
PLEASE RESPOND IMMEDIATELY.”
The message is repeated two
times. At any point during the
message, the called party can enter
a code as described in EMERGENCY
DIAL OUT to log in and stop the
Model 1503 from dialing any further
numbers.
If the called party is busy,
does not answer, or answers but
does not enter a code, then the
Model 1503 goes to the MEDICAL DIAL
ORDER to determine the next number
to dial, and the next call is made.
- The console display will read
“FIRE ALARM - FIRE EMG BTN
TRIPPED”.
- The Central Station (if used)
will receive a Fire Emergency
Button signal.
- The voice dialer dials out using
the FIRE DIAL ORDER with the
following message: “EMERGENCY...
EMERGENCY... THE FIRE EMERGENCY
BUTTON HAS BEEN ACTIVATED AT THE
FOLLOWING ADDRESS: (your address
is spoken here*) PHONE NUMBER
(your phone number) PLEASE RE-
SPOND IMMEDIATELY.
The FIRE EMERGENCY alarm can be
turned off at any time by turning
the security system off or by
pressing CANCEL.
MEDICAL EMERGENCY BUTTON
PRESSED
When the MEDICAL EMERGENCY BUT-
TON is pressed:
- Console beeper comes on - dis-
play indicates “EMERGENCY ALARM!
- MEDICAL EMG BTN TRIPPED”
- The ON FOR ALARM UNIT NUMBERS
are turned on.
- The FLASH FOR ALARM UNIT NUMBER
begins to flash on and off.
- The system waits the DIAL OUT
DELAY.
- The in house phones are seized
(or disconnected) and the Model
1503 begins to dial out.
