Specifications
Power Supply NTSC model: 120 V AC, 60 Hz
PAL model: 220 V - 240 V AC, 50 Hz
Power Consumption: 60 W
Controllable Encoders (NTSC model only): 256 Encoders
Controllable Decoders (NTSC model only): 64 Decoders
Ethernet Ports: 10Base-T/100Base-TX, 8-conductor modular jack (x3)
System controller* (1 port), encoder and decoder control (1 port)**, other (1 port)
* Maximum 64 controllers
** NTSC model only
RS-232C Port: 9-pin D-sub connector (x2)
Ambient Operating Temperature: +5 °C to +45 °C {41 °F - 113 °F}
Ambient Operating Humidity: Less than 90 %
Dimensions 420 mm (W) x 88 mm (H) x 350 (D) mm
(excluding rubber feet and projections): {16-9/16" (W) x 3-7/16" (H) x 13-3/4" (D)}
Weight: 9 kg {19.8 lbs.}
Weight and dimensions indicated are approximate.
Specifications are subject to change without notice.
Standard Accessories
Installation Guide ............................................................. 1 pc.
CD-ROM ........................................................................... 1 pc.
Note: The files specified below are included on the CD-ROM.
Operating Instructions (pdf)
Administration Console
The following are for installation:
Power Cord*
NTSC model: ............................................................... 1 pc.
PAL model: .................................................................. 2 pcs.
Mounting Brackets............................................................ 2 pcs.
Mounting Screws .............................................................. 8 pcs.
* Use the power cord that is suited to your locality.
Information on Disposal for Users of Waste Electrical & Electronic Equipment (private households)
This symbol on the products and/or accompanying documents means that used electrical and electronic products should not be
mixed with general household waste.
For proper treatment, recovery and recycling, please take these products to designated collection points, where they will be
accepted on a free of charge basis. Alternatively, in some countries you may be able to return your products to your local retailer
upon the purchase of an equivalent new product.
Disposing of this product correctly will help to save valuable resources and prevent any potential negative effects on human
health and the environment which could otherwise arise from inappropriate waste handling. Please contact your local authority
for further details of your nearest designated collection point.
Penalties may be applicable for incorrect disposal of this waste, in accordance with national legislation.
For business users in the European Union
If you wish to discard electrical and electronic equipment, please contact your dealer or supplier for further information.
Information on Disposal in other Countries outside the European Union
This symbol is only valid in the European Union.
If you wish to discard this product, please contact your local authorities or dealer and ask for the correct method of disposal.
