59
4. Press the PRESET/PGM PRESET button while holding
down the SHIFT button. The preset position will be
saved.
Note: If the entered position number has stored the previ-
ous preset position, it will be overwritten by the new
one.
●
Call Preset Position
1. Select the desired monitor and camera. (Refer to p. 56
Monitor Selection and Camera Selection.)
2. To select the desired preset position number, press the
numeric buttons.
Notes:
• When you have selected a wrong number, press
the CLEAR button to clear the numeric input.
• WJ-MPU955A supports up to 255 preset positions.
3. Press the PRESET/PGM PRESET button. The camera
will move to the preset position, and the image of
selected preset position will be displayed on the active
monitor.
Note: To call preset positions, you must set preset
position numbers for the camera in advance.
■
Wiper Control
The following procedure is available when a selected cam-
era (housing) is equipped with a wiper.
1. Select the desired monitor and camera. (Refer to p. 56
Monitor Selection and Camera Selection.)
2. Keep pressing the WIPER button.
The wiper will be activated while this button is being
pressed.
Note: When the WIPER button is released, the LCD dis-
play will become as follows.
MON PrgPre:15 CAM
0123 Unit:01 00512
MON 15 CAM
0123 Unit:01 00512
MON Preset:15 CAM
0123 Unit:01 00512
MON Wiper On CAM
0123 Unit:01 00512
MON Wiper Off CAM
0123 Unit:01 00512
