Alarm Status Table
The table shows the alarm statuses.
1. Select a desired monitor. (Refer to p. 56 Monitor
Selection.)
2. Display "AlmStat" menu. (Refer to Step 1 and 2 of p. 77
To Recall Menu Functions.)
3. Select a desired function by pressing one of the F1 to
F3 buttons.
Available buttons and functions
F1: On
Opens the ALARM STATUS table.
F2: Off
Closes the ALARM STATUS table.
F3: Blk
Changes the monitor background beween camera
images and black picture.
NAME: Alarm text
(Refer to p. 66 for other columns on the table.)
4. To display the next page, press the + button.
To display the previous page, press the – button.
Notes:
• To display the first page of table, press the + but-
ton while holding down the SHIFT button.
• To display the last page of table, press the – button
while holding down the SHIFT button.
5. To exit the ALARM STATUS table, perform one of the
following.
• Select a camera. (Refer to p. 56 Camera Selection.)
• Press F2, then press the MON(ESC) button.
• Press F2, then press the EXIT button.
■
Video Loss Status Table
The table shows the video loss detection statuses.
1. Select a desired monitor. (Refer to p. 56 Monitor
Selection.)
2. Display "VL Stat" menu. (Refer to Step 1 and 2 of p. 77
To Recall Menu Functions.)
3. Select a desired function by pressing one of the F1 to
F3 buttons.
Available buttons and functions
F1: On
Opens the VIDEO LOSS STATUS table.
F2: Off
Closes the VIDEO LOSS STATUS table.
F3: Blk
Changes the monitor background beween camera
images and black picture.
CAM: Logical camera number
PORT#: Video input port number
NODE: Video switch node type
STATUS:
ABV/IN: Video level is above normal and in sync.
BLW/IN: Video level is below normal and in sync.
ABV/OUT: Video level is above normal and out of
sync.
BLW/OUT: Video level is below normal and out of
sync.
LOCATION: Logical cage number that the port
belongs to.
4. To display the next page, press the + button.
To display the previous page, press the – button.
Notes:
• To display the first page of table, press the + but-
ton while holding down the SHIFT button.
• To display the last page of table, press the – button
while holding down the SHIFT button.
5. To exit the VIDEO LOSS table, perform either of the fol-
lowing.
• Select a camera. (Refer to p. 56 Camera Selection.)
• Press F2, then press the MON(ESC) button.
• Press F2, then press the EXIT button.
ALARM STATUS PG
ALM STATE NAME
1 DISARMED FRONT DOOR
1 ARMED BACK DOOR
1 ACTIVE –
1 ACKED –
1 CLEARED –
1 RESET –
AlmStat: 008
On Off Blk
VL Stat: 009
On Off Blk
VIDEO LOSS STATUS PG
CAM PORT NODE STATUS LOCATION
6400 999 SX ABV/IN 1234567890
6400 999 SX ABV/OUT 1234567890
6400 999 SX BLW/IN 1234567890
6400 999 SX BLW/OUT 1234567890
