78
Menu Function Details
■
Camera Setup
Notes:
• The following function requires the use of cameras sup-
porting this function.
• The details on the setup menu differ depending on
camera models. Refer to WV-CU950/650 Operating
Instructions and the Operating Instructions of camera
for available controls on the camera setup menu.
1. Select a desired monitor. (Refer to p.
56
Monitor
Selection.)
2. Display "CamMenu" menu. (Refer to Step 1 and 2 of p.
77
To Recall Menu Functions.)
3. Select a desired function by pressing one of the F1 to
F4 buttons.
Available buttons and functions
F1: On
Opens the setup menu of selected camera.
F2: Off
Closes the setup menu of selected camera.
F3: Rst
• Displays the special menu.
• To restore the default camera position, move the
cursor to REFRESH on the camera setup menu by
moving the 3D joystick. Then, press this button.
F4: A.Rst
To reset all the camera settings to the factory default,
move the cursor to CAMERA RESET on the camera
setup menu by moving the 3D joystick. Then, press this
button.
Note: Depending on the camera model, "CAMERA
RESET" is not displayed on the camera setup menu.
In this case, the F4 button is unavailable.
■
Auto Mode
1. Select a desired monitor and camera. (Refer to p.
56
Monitor Selection and Camera Selection.)
2. Display "Auto Mod" menu. (Refer to Step 1 and 2 of p.
77
To Recall Menu Functions.)
3. Select a desired function by pressing one of the F1 to
F4 buttons.
Available buttons and functions
F1: Seq
Activates the sequence mode.
F2: Sort
Activates the sort mode.
F3: Pan
Activates the auto pan mode.
F4: Patrol
Activates the patrol mode.
■
BW Mode
1. Select a desired monitor and camera. (Refer to p.
56
Monitor Selection and Camera Selection.)
2. Display "BW Mode" menu. (Refer to Step 1 and 2 of p.
77
To Recall Menu Functions.)
3. Select a desired function by pressing one of the F1 to
F4 buttons.
Available buttons and functions
F1: On
Changes the camera image from color (colour) to black
and white.
F2: Off
Changes the camera image from black and white to
color (colour).
F3: Auto1
Activates Auto 1 mode. (The camera selects black and
white mode if the picture is dark, or color (colour) mode
if the picture is bright enough.)
F4: Auto2
Activates Auto 2 mode. (The camera detects the light
source type to prevent malfunction. This setting is
applicable when using a near-infrared light source in a
dark place.)
CamMenu: 001
On
5
Off Rst A.Rst
AutoMod: 002
Seq Sort Pan Patrol
BW Mode: 003
On Off Auto1 Auto2
