*2-2 Loop-thru Connection between SubNode 2 and SubNode 5
SubNode 2 SubNode 5
VIDEO OUT 1 (Input Board (1)) Camera Input Connecters 1 to 8 (Input Board (1))
VIDEO OUT 2 (Input Board (1)) Camera Input Connecters 9 to 16 (Input Board (1))
VIDEO OUT 3 (Input Board (1)) Camera Input Connecters 17 to 24 (Input Board (1))
VIDEO OUT 4 (Input Board (1)) Camera Input Connecters 25 to 32 (Input Board (1))
VIDEO OUT 1 (Input Board (2)) Camera Input Connecters 1 to 8 (Input Board (2))
VIDEO OUT 2 (Input Board (2))
VIDEO OUT 3 (Input Board (2))
Camera Input Connecters 9 to 16 (Input Board (2))
Camera Input Connecters 17 to 24 (Input Board (2))
VIDEO OUT 4 (Input Board (2)) Camera Input Connecters 25 to 32 (Input Board (2))
VIDEO OUT 1 (Input Board (3)) Camera Input Connecters 1 to 8 (Input Board (3))
VIDEO OUT 2 (Input Board (3)) Camera Input Connecters 9 to 16 (Input Board (3))
VIDEO OUT 3 (Input Board (3)) Camera Input Connecters 17 to 24 (Input Board (3))
VIDEO OUT 4 (Input Board (3)) Camera Input Connecters 25 to 32 (Input Board (3))
VIDEO OUT 1 (Input Board (4)) Camera Input Connecters 1 to 8 (Input Board (4))
VIDEO OUT 2 (Input Board (4)) Camera Input Connecters 9 to 16 (Input Board (4))
VIDEO OUT 3 (Input Board (4)) Camera Input Connecters 17 to 24 (Input Board (4))
VIDEO OUT 4 (Input Board (4)) Camera Input Connecters 25 to 32 (Input Board (4))
VIDEO OUT 1 (Input Board (5)) Camera Input Connecters 1 to 8 (Input Board (5))
VIDEO OUT 2 (Input Board (5)) Camera Input Connecters 9 to 16 (Input Board (5))
VIDEO OUT 3 (Input Board (5)) Camera Input Connecters 17 to 24 (Input Board (5))
VIDEO OUT 4 (Input Board (5)) Camera Input Connecters 25 to 32 (Input Board (5))
VIDEO OUT 1 (Input Board (6)) Camera Input Connecters 1 to 8 (Input Board (6))
VIDEO OUT 2 (Input Board (6)) Camera Input Connecters 9 to 16 (Input Board (6))
VIDEO OUT 3 (Input Board (6)) Camera Input Connecters 17 to 24 (Input Board (6))
VIDEO OUT 4 (Input Board (6)) Camera Input Connecters 25 to 32 (Input Board (6))
VIDEO OUT 1 (Input Board (7)) Camera Input Connecters 1 to 8 (Input Board (7))
VIDEO OUT 2 (Input Board (7)) Camera Input Connecters 9 to 16 (Input Board (7))
VIDEO OUT 3 (Input Board (7)) Camera Input Connecters 17 to 24 (Input Board (7))
VIDEO OUT 4 (Input Board (7)) Camera Input Connecters 25 to 32 (Input Board (7))
VIDEO OUT 1 (Input Board (8)) Camera Input Connecters 1 to 8 (Input Board (8))
VIDEO OUT 2 (Input Board (8)) Camera Input Connecters 9 to 16 (Input Board (8))
VIDEO OUT 3 (Input Board (8)) Camera Input Connecters 17 to 24 (Input Board (8))
VIDEO OUT 4 (Input Board (8)) Camera Input Connecters 25 to 32 (Input Board (8))
Note: For the loop-thru connections, use the WJ-CA68 and regular coaxial cables.
