Connect with Each SX650 SubNode via Coaxial Cables

*1-1 Video Connection between SubNode 1 and SubNode 3 (Bridge)

SubNode 1 SubNode 3

Monitor Output Connectors 1 (Output Board (1)) Camera Input Connecters 1 (Input Board (1))

::

Monitor Output Connectors 16 (Output Board (1)) Camera Input Connecters 16 (Input Board (1))

Monitor Output Connectors 1 (Output Board (2)) Camera Input Connecters 17 (Input Board (1))

::

Monitor Output Connectors 16 (Output Board (2)) Camera Input Connecters 32 (Input Board (1))

*1-2 Video Connection between SubNode 2 and SubNode 3 (Bridge)

SubNode 3

Monitor Output Connectors 1 (Output Board (1)) Camera Input Connecters 1 (Input Board (2))

::

Monitor Output Connectors 16 (Output Board (1)) Camera Input Connecters 16 (Input Board (2))

Monitor Output Connectors 1 (Output Board (2)) Camera Input Connecters 17 (Input Board (2))

::

Monitor Output Connectors 16 (Output Board (2)) Camera Input Connecters 32 (Input Board (2))

Note: To make the video switching work as non-blocking, the all 32 outputs of SubNode 1 and SubNode 2 should be connect-

ed to SubNode 3 inputs.

*1-3 Video Connection between SubNode 4 and SubNode 6 (Bridge)

SubNode 6

Monitor Output Connectors 1 (Output Board (1)) Camera Input Connecters 1 (Input Board (1))

::

Monitor Output Connectors 16 (Output Board (1)) Camera Input Connecters 16 (Input Board (1))

Monitor Output Connectors 1 (Output Board (2)) Camera Input Connecters 17 (Input Board (1))

::

Monitor Output Connectors 16 (Output Board (2)) Camera Input Connecters 32 (Input Board (1))

*1-4 Video Connection between SubNode 5 and SubNode 6 (Bridge)

SubNode 6

Monitor Output Connectors 1 (Output Board (1)) Camera Input Connecters 1 (Input Board (2))

::

Monitor Output Connectors 16 (Output Board (1)) Camera Input Connecters 16 (Input Board (2))

Monitor Output Connectors 1 (Output Board (2)) Camera Input Connecters 17 (Input Board (2))

::

Monitor Output Connectors 16 (Output Board (2)) Camera Input Connecters 32 (Input Board (2))

Note: To make the video switching work as non-blocking, the all 32 outputs of SubNode 4 and SubNode 5 should be connect-

ed to SubNode 6 inputs.
