528150-YTG-G-1210
Johnson Controls Unitary Products 89
115°F 125°F
2500
77 114.7 11.7 43.6 38.1 27.5 - - - 104.7 12.9 36.1 33.8 23.4 - - -
72 105.4 11.5 66.6 55.9 45.3 34.6 - - 96.1 12.7 61.8 51.4 41.1 30.7 - -
67 96.1 11.4 89.6 73.7 63.1 52.4 41.8 - 87.5 12.5 87.5 69.1 58.7 48.4 38.0 -
62 88.1 11.2 88.1 88.1 73.2 62.5 51.9 41.2 81.5 12.3 81.5 81.5 66.3 55.9 45.6 35.2
3000
77 118.9 11.7 55.7 43.1 30.6 - - - 108.1 12.9 50.9 38.6 26.2 - - -
72 109.3 11.6 75.5 62.9 50.3 37.8 - - 99.2 12.7 70.6 58.3 46.0 33.7 - -
67 99.6 11.4 95.3 82.7 70.1 57.6 45.0 - 90.4 12.6 90.4 78.1 65.8 53.4 41.1 -
62 91.3 11.2 91.3 91.3 81.4 68.8 56.3 43.7 84.2 12.3 84.2 84.2 74.3 62.0 49.7 37.3
57 88.0 11.5 88.0 88.0 78.4 65.9 53.3 40.7 79.2 12.8 79.2 79.2 69.2 56.9 44.6 32.2
3500
77 123.1 11.8 67.8 48.1 33.6 - - - 111.5 13.0 65.7 43.4 29.1 - - -
72 113.1 11.6 84.4 69.9 55.4 40.9 - - 102.4 12.8 79.5 65.2 50.9 36.7 - -
67 103.1 11.5 101.0 91.7 77.2 62.7 48.2 - 93.3 12.6 93.3 87.1 72.8 58.5 44.3 -
62 94.6 11.3 94.6 94.6 89.6 75.1 60.6 46.1 86.9 12.4 86.9 86.9 82.3 68.0 53.8 39.5
57 91.1 11.6 91.1 91.1 86.3 71.8 57.4 42.9 81.7 12.8 81.7 81.7 76.7 62.4 48.2 33.9
4000
77 127.3 11.8 79.9 53.1 36.7 - - - 114.9 13.0 80.5 48.2 31.9 - - -
72 117.0 11.7 93.3 76.9 60.5 44.1 - - 105.5 12.8 88.3 72.1 55.9 39.7 - -
67 106.7 11.5 106.7 100.7 84.3 67.9 51.5 - 96.1 12.6 96.1 96.0 79.8 63.6 47.4 -
62 97.8 11.3 97.8 97.8 97.8 81.4 65.0 48.6 89.6 12.4 89.6 89.6 89.6 74.1 57.9 41.6
57 94.2 11.6 94.2 94.2 94.2 77.8 61.4 45.0 84.2 12.9 84.2 84.2 84.2 68.0 51.7 35.5
4500
72 116.8 11.7 99.2 81.7 64.2 46.7 - - 104.7 12.8 93.8 76.6 59.4 42.1 - -
67 106.4 11.5 106.4 103.4 89.5 72.0 54.5 - 95.4 12.7 95.4 95.4 84.8 67.5 50.3 -
62 97.6 11.3 97.6 97.6 97.6 80.1 62.6 45.1 88.9 12.4 88.9 88.9 88.9 72.0 54.8 37.6
57 94.0 11.6 94.0 94.0 94.0 76.5 59.0 41.5 83.5 12.9 83.5 83.5 83.5 66.3 49.0 31.8
5000
72 116.5 11.7 105.2 86.6 68.0 49.4 - - 104.0 12.8 99.4 81.1 62.8 44.6 - -
67 106.2 11.5 106.2 106.2 94.7 76.1 57.5 - 94.7 12.7 94.7 94.7 89.7 71.5 53.2 -
62 97.4 11.3 97.4 97.4 97.4 78.8 60.2 41.6 88.3 12.4 88.3 88.3 88.3 70.0 51.7 33.5
57 93.9 11.6 93.9 93.9 93.9 75.3 56.7 38.1 82.9 12.9 82.9 82.9 82.9 64.6 46.3 28.1
1. These capacities are gross ratings. For net capacity, deduct air blower motor, MBh = 3.415 x kW. Refer to the appropriate Blower
Performance Table for the kW of the supply air blower motor.
2. These ratings include the condenser fan motors (total 1 kW) and the compressor motors but not the supply air blower motor.
ZR120 (10 Ton) Cooling (Continued)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
