528150-YTG-G-1210
60 Johnson Controls Unitary Products
115°F 125°F
1875
77 90.4 8.3 33.6 30.2 21.8 - - - 81.7 8.9 32.0 25.5 18.7 - - -
72 81.1 8.0 51.6 43.1 34.6 26.2 - - 72.9 8.6 48.1 39.7 31.4 23.0 - -
67 71.9 7.8 69.5 56.0 47.5 39.0 30.6 - 64.1 8.3 64.1 52.4 44.0 35.7 27.3 -
62 63.9 7.6 63.9 63.9 59.0 50.5 42.0 33.6 57.3 8.1 57.3 57.3 57.3 46.5 38.2 29.8
2250
77 92.7 8.3 43.8 33.9 24.0 - - - 83.2 9.0 43.2 30.5 20.7 - - -
72 83.2 8.1 58.0 48.1 38.2 28.3 - - 74.3 8.7 54.3 44.5 34.8 25.0 - -
67 73.7 7.9 72.2 62.3 52.4 42.5 32.6 - 65.3 8.4 65.3 58.5 48.8 39.0 29.3 -
62 65.6 7.7 65.6 65.6 65.1 55.2 45.3 35.4 58.4 8.2 58.4 58.4 58.4 51.1 41.3 31.6
57 68.8 7.7 68.8 68.8 61.5 51.6 41.7 31.8 62.7 8.3 62.7 62.7 56.0 46.3 36.5 26.8
2625
77 95.1 8.4 53.9 37.5 26.3 - - - 84.8 9.1 54.4 35.5 22.8 - - -
72 85.4 8.2 64.4 53.1 41.8 30.5 - - 75.7 8.8 60.5 49.3 38.2 27.0 - -
67 75.6 7.9 74.8 68.6 57.3 46.0 34.7 - 66.5 8.5 66.5 64.7 53.5 42.4 31.2 -
62 67.2 7.7 67.2 67.2 71.2 59.9 48.6 37.3 59.5 8.2 59.5 59.5 59.5 55.6 44.5 33.3
57 70.6 7.8 70.6 70.6 67.2 55.9 44.6 33.3 63.9 8.4 63.9 63.9 61.5 50.4 39.2 28.0
3000
77 97.5 8.5 64.0 41.2 28.5 - - - 86.4 9.1 65.7 40.5 24.8 - - -
72 87.5 8.2 70.8 58.1 45.4 32.6 - - 77.1 8.8 66.7 54.1 41.6 29.0 - -
67 77.5 8.0 77.5 74.9 62.2 49.5 36.8 - 67.8 8.6 67.8 67.8 58.3 45.8 33.2 -
62 68.9 7.8 68.9 68.9 77.2 64.5 51.8 39.1 60.6 8.3 60.6 60.6 60.6 60.2 47.6 35.0
57 72.3 7.9 72.3 72.3 73.0 60.3 47.6 34.8 65.1 8.4 65.1 65.1 65.1 54.4 41.9 29.3
3375
72 88.7 8.3 77.5 63.3 49.1 34.8 - - 77.7 8.9 73.3 59.2 45.1 31.0 - -
67 78.6 8.0 78.6 77.3 67.3 53.1 38.8 - 68.3 8.6 68.3 68.3 63.3 49.2 35.1 -
62 69.9 7.8 69.9 69.9 74.1 59.8 45.6 31.4 61.1 8.4 61.1 61.1 61.1 53.1 39.0 24.9
57 73.4 7.9 73.4 73.4 73.7 59.5 45.2 31.0 65.7 8.5 65.7 65.7 65.7 52.5 38.4 24.3
3750
72 90.0 8.3 84.3 68.5 52.8 37.0 - - 78.4 8.9 78.4 64.3 48.6 33.0 - -
67 79.7 8.1 79.7 79.7 72.4 56.6 40.9 - 68.9 8.6 68.9 68.9 68.2 52.6 37.0 -
62 70.9 7.9 70.9 70.9 70.9 55.1 39.4 23.6 61.6 8.4 61.6 61.6 61.6 46.0 30.4 14.8
57 74.4 7.9 74.4 74.4 74.4 58.7 42.9 27.2 66.3 8.5 66.3 66.3 66.3 50.6 35.0 19.4
1. These capacities are gross ratings. For net capacity, deduct air blower motor, MBh = 3.415 x kW. Refer to the appropriate Blower
Performance Table for the kW of the supply air blower motor.
2. These ratings include the condenser fan motors (total 1 kW) and the compressor motors but not the supply air blower motor.
ZJ090 (7.5 Ton) (Continued)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
