528150-YTG-G-1210
Johnson Controls Unitary Products 37
ZH049 (4.0 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
1000
77 65.4 3.0 28.0 23.5 19.1 - - - 60.3 3.3 25.1 20.8 16.4 - - -
72 59.2 3.0 34.8 30.3 25.9 21.4 - - 54.5 3.3 31.8 27.5 23.2 18.9 - -
67 53.0 2.9 41.6 37.1 32.7 28.3 23.8 - 48.8 3.2 38.6 34.2 29.9 25.6 21.3 -
62 47.0 2.9 47.0 47.0 40.3 35.9 31.4 27.0 43.1 3.2 43.1 43.1 37.1 32.8 28.5 24.1
1200
77 68.3 3.0 30.8 25.6 20.4 - - - 62.9 3.3 27.9 22.9 17.8 - - -
72 61.8 3.0 38.0 32.9 27.7 22.5 - - 56.9 3.3 35.2 30.2 25.1 20.1 - -
67 55.3 2.9 45.3 40.1 35.0 29.8 24.6 - 50.9 3.2 42.5 37.5 32.4 27.4 22.3 -
62 49.1 2.9 49.1 49.1 43.1 38.0 32.8 27.6 45.0 3.2 45.0 45.0 40.2 35.2 30.1 25.1
57 48.9 2.9 48.9 48.9 47.1 42.0 36.8 31.6 44.8 3.2 44.8 44.8 42.3 37.2 32.2 27.1
1400
77 71.2 3.0 33.6 27.7 21.8 - - - 65.5 3.3 30.7 25.0 19.2 - - -
72 64.4 3.0 41.3 35.4 29.5 23.6 - - 59.2 3.3 38.6 32.9 27.1 21.3 - -
67 57.7 2.9 49.0 43.1 37.3 31.4 25.5 - 52.9 3.2 46.5 40.7 35.0 29.2 23.4 -
62 51.1 2.9 51.1 51.1 46.0 40.1 34.2 28.3 46.8 3.2 46.8 46.8 43.3 37.6 31.8 26.0
57 51.0 2.9 51.0 51.0 50.3 44.4 38.5 32.6 46.6 3.2 46.6 46.6 45.5 39.8 34.0 28.2
1600
77 74.1 3.0 36.4 29.8 23.2 - - - 68.1 3.4 33.6 27.1 20.6 - - -
72 67.1 3.0 44.6 38.0 31.4 24.7 - - 61.5 3.3 42.0 35.5 29.0 22.5 - -
67 60.0 2.9 52.8 46.1 39.5 32.9 26.3 - 55.0 3.3 50.5 44.0 37.5 31.0 24.5 -
62 53.2 2.9 53.2 53.2 48.8 42.1 35.5 28.9 48.7 3.2 48.7 48.7 46.5 40.0 33.5 27.0
57 53.1 2.9 53.1 53.1 53.4 46.8 40.2 33.5 48.4 3.2 48.4 48.4 48.8 42.3 35.8 29.3
1800
72 69.2 3.0 48.1 40.9 33.6 26.4 - - 63.4 3.4 45.4 38.3 31.2 24.0 - -
67 62.0 3.0 58.3 49.6 42.4 35.2 28.0 - 56.7 3.3 54.4 47.4 40.2 33.1 26.0 -
62 54.9 3.0 54.9 54.9 52.7 45.5 38.3 31.1 50.1 3.3 50.1 50.1 49.0 41.9 34.8 27.7
57 54.8 2.9 54.8 54.8 54.9 47.7 40.5 33.3 49.9 3.2 49.9 49.9 50.1 43.0 35.8 28.7
2000
72 71.4 3.1 51.6 43.7 35.9 28.1 - - 65.2 3.4 48.8 41.0 33.3 25.6 - -
67 63.9 3.0 63.9 53.1 45.3 37.5 29.7 - 58.3 3.3 58.3 50.7 43.0 35.2 27.5 -
62 56.6 3.0 56.6 56.6 56.6 48.8 41.0 33.2 51.6 3.3 51.6 51.6 51.6 43.9 36.1 28.4
57 56.5 3.0 56.5 56.5 56.5 48.6 40.8 33.0 51.4 3.3 51.4 51.4 51.4 43.6 35.9 28.1
95°F 105°F
1000
77 55.3 3.6 22.2 18.0 13.8 - - - 50.6 4.0 19.3 16.2 12.1 - - -
72 49.9 3.6 28.9 24.7 20.5 16.3 - - 45.4 3.9 26.7 22.7 18.6 14.5 - -
67 44.5 3.5 35.5 31.3 27.1 22.9 18.7 - 40.1 3.8 34.2 29.1 25.1 21.0 16.9 -
62 39.3 3.4 39.3 39.3 33.9 29.7 25.5 21.3 36.2 3.7 36.2 36.2 30.9 26.9 22.8 18.7
1200
77 57.5 3.6 25.1 20.1 15.2 - - - 52.4 4.0 22.9 18.2 13.4 - - -
72 51.9 3.6 32.4 27.5 22.6 17.6 - - 47.0 3.9 30.1 25.3 20.5 15.7 - -
67 46.4 3.5 39.8 34.8 29.9 25.0 20.0 - 41.5 3.8 37.3 32.5 27.7 22.9 18.1 -
62 40.9 3.4 40.9 40.9 37.3 32.4 27.4 22.5 37.5 3.7 37.5 37.5 34.2 29.4 24.6 19.8
57 40.6 3.5 40.6 40.6 37.4 32.4 27.5 22.6 37.1 3.7 37.1 37.1 33.8 29.0 24.2 19.4
1400
77 59.8 3.7 27.9 22.3 16.6 - - - 54.3 4.0 26.6 20.1 14.6 - - -
72 54.0 3.6 35.9 30.3 24.6 19.0 - - 48.6 3.9 33.5 28.0 22.5 17.0 - -
67 48.2 3.6 44.0 38.3 32.6 27.0 21.3 - 43.0 3.8 40.4 35.8 30.3 24.8 19.3 -
62 42.5 3.5 42.5 42.5 40.7 35.1 29.4 23.7 38.8 3.8 38.8 38.8 37.4 31.9 26.4 20.9
57 42.2 3.5 42.2 42.2 40.8 35.1 29.5 23.8 38.4 3.8 38.4 38.4 37.0 31.4 25.9 20.4
1600
77 62.0 3.7 30.8 24.4 18.0 - - - 56.1 4.1 30.3 22.1 15.9 - - -
72 56.0 3.6 39.5 33.1 26.7 20.3 - - 50.2 4.0 36.9 30.6 24.4 18.2 - -
67 50.0 3.6 48.2 41.8 35.4 29.0 22.6 - 44.4 3.9 43.5 39.2 32.9 26.7 20.5 -
62 44.1 3.5 44.1 44.1 44.1 37.8 31.4 25.0 40.1 3.8 40.1 40.1 40.7 34.4 28.2 22.0
57 43.8 3.5 43.8 43.8 44.2 37.8 31.5 25.1 39.7 3.8 39.7 39.7 40.2 33.9 27.7 21.5
1800
72 57.6 3.7 42.7 35.7 28.7 21.7 - - 51.6 4.0 40.1 33.2 26.3 19.5 - -
67 51.4 3.6 50.5 45.1 38.0 31.0 24.0 - 45.6 3.9 45.2 41.9 35.5 28.6 21.8 -
62 45.3 3.5 45.3 45.3 45.3 38.3 31.3 24.3 41.2 3.8 41.2 41.2 41.5 34.6 27.7 20.8
57 45.0 3.6 45.0 45.0 45.2 38.2 31.2 24.2 40.8 3.8 40.8 40.8 41.0 34.1 27.2 20.4
2000
72 59.1 3.7 46.0 38.3 30.7 23.0 - - 53.0 4.1 43.3 35.8 28.3 20.7 - -
67 52.7 3.7 52.7 48.3 40.7 33.0 25.3 - 46.8 4.0 46.8 44.6 38.1 30.6 23.1 -
62 46.5 3.6 46.5 46.5 46.5 38.9 31.2 23.6 42.2 3.9 42.2 42.2 42.2 34.7 27.2 19.6
57 46.2 3.6 46.2 46.2 46.2 38.6 30.9 23.2 41.8 3.9 41.8 41.8 41.8 34.3 26.8 19.2
