528150-YTG-G-1210
194 Johnson Controls Unitary Products
ZH/ZJ/ZR037-150 Unit Dimensions
ZH037-061 and ZJ/ZR037
ZH/ZJ/ZR037-150 Unit Accessory Weights
Unit Accessory
Weight (lbs.)
Shipping Operating
Economizer 90 85
Power Exhaust 40 35
Electric Heat
1
1. Weight given is for the maximum heater size available
(54KW).
49 49
Gas Heat
2
2. Weight given is for the maximum number of tube heat
exchangers available (8 tube).
110 110
Variable Frequency Drive
3
3. Weight includes mounting hardware, controls and manual
bypass option (6-1/2 to 12-1/2 ton only).
30 30
Ø 25.31
59.00
15.51
29.75
59
LEFT
11 3/8
21 3/16
89
27 5/16
4 3/16
FRONT
See detail A for gas inlet
A
See detail B for drain location
B
C
D
E
F
29.52
