528150-YTG-G-1210
Johnson Controls Unitary Products 55
ZJ061 (5.0 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
1250
77 79.8 3.1 35.0 28.5 22.5 - - - 74.2 3.6 32.0 26.2 20.4 - - -
72 72.2 3.1 42.9 36.9 30.9 24.9 - - 67.2 3.6 40.3 34.4 28.6 22.8 - -
67 64.6 3.2 50.8 45.3 39.3 33.2 27.2 - 60.1 3.6 48.5 42.7 36.9 31.1 25.3 -
62 57.1 3.1 57.1 57.1 47.4 41.4 35.4 29.4 53.6 3.5 53.6 53.6 44.7 38.9 33.0 27.2
1500
77 83.4 3.1 38.6 31.7 24.8 - - - 77.3 3.6 36.0 29.3 22.5 - - -
72 75.5 3.2 47.8 40.9 34.0 27.1 - - 70.0 3.6 45.1 38.4 31.6 24.9 - -
67 67.5 3.2 57.1 50.1 43.2 36.3 29.3 - 62.7 3.6 54.3 47.5 40.8 34.0 27.3 -
62 59.7 3.1 59.7 59.7 52.2 45.2 38.3 31.4 55.9 3.5 55.9 55.9 49.4 42.6 35.9 29.1
57 59.9 3.2 59.9 59.9 55.9 49.0 42.0 35.1 54.8 3.6 54.8 54.8 50.3 43.6 36.9 30.1
1750
77 87.0 3.2 42.3 34.9 27.0 - - - 80.4 3.7 40.0 32.3 24.7 - - -
72 78.8 3.2 52.8 44.9 37.1 29.2 - - 72.8 3.7 50.0 42.3 34.7 27.0 - -
67 70.5 3.2 63.3 55.0 47.1 39.3 31.4 - 65.2 3.6 60.0 52.3 44.7 37.0 29.3 -
62 62.3 3.1 62.3 62.3 56.9 49.1 41.2 33.4 58.1 3.6 58.1 58.1 54.1 46.4 38.7 31.0
57 62.4 3.2 62.4 62.4 61.0 53.2 45.3 37.5 57.0 3.6 57.0 57.0 55.1 47.5 39.8 32.1
2000
77 90.6 3.2 45.9 38.0 29.3 - - - 83.5 3.7 44.0 35.4 26.8 - - -
72 82.0 3.2 57.7 48.9 40.2 31.4 - - 75.6 3.7 54.9 46.3 37.7 29.1 - -
67 73.4 3.2 69.5 59.8 51.1 42.3 33.6 - 67.7 3.7 65.7 57.1 48.5 39.9 31.3 -
62 64.9 3.2 64.9 64.9 61.7 52.9 44.2 35.4 60.4 3.6 60.4 60.4 58.8 50.2 41.5 32.9
57 65.0 3.2 65.0 65.0 66.1 57.4 48.6 39.9 59.2 3.6 59.2 59.2 59.9 51.3 42.7 34.1
2250
72 84.2 3.2 62.2 52.6 43.0 33.4 - - 77.4 3.7 59.3 49.9 40.4 30.9 - -
67 75.4 3.2 73.4 64.3 54.7 45.1 35.5 - 69.3 3.7 68.3 61.5 52.0 42.6 33.1 -
62 66.6 3.2 66.6 66.6 65.0 55.4 45.8 36.2 61.8 3.6 61.8 61.8 61.0 51.5 42.1 32.6
57 66.8 3.2 66.8 66.8 67.3 57.7 48.1 38.5 60.7 3.6 60.7 60.7 61.0 51.5 42.1 32.6
2500
72 86.4 3.2 66.8 56.3 45.9 35.5 - - 79.2 3.7 63.7 53.4 43.1 32.8 - -
67 77.3 3.2 77.3 68.8 58.3 47.9 37.5 - 70.9 3.7 70.9 65.9 55.6 45.2 34.9 -
62 68.4 3.2 68.4 68.4 68.4 57.9 47.5 37.1 63.2 3.6 63.2 63.2 63.2 52.9 42.6 32.3
57 68.5 3.2 68.5 68.5 68.5 58.1 47.6 37.2 62.1 3.6 62.1 62.1 62.1 51.8 41.5 31.1
95°F 105°F
1250
77 68.5 4.1 29.0 23.9 18.2 - - - 63.5 4.5 25.6 22.1 16.6 - - -
72 62.1 4.1 37.6 32.0 26.4 20.8 - - 57.3 4.4 35.7 30.1 24.6 19.1 - -
67 55.7 4.0 46.2 40.1 34.5 28.9 23.3 - 51.0 4.4 45.7 38.1 32.6 27.1 21.5 -
62 50.1 4.0 50.1 50.1 41.9 36.3 30.7 25.1 46.7 4.3 46.7 46.7 38.4 32.8 27.3 21.8
1500
77 71.1 4.1 33.4 26.8 20.3 - - - 65.8 4.5 31.5 25.0 18.5 - - -
72 64.5 4.1 42.4 35.9 29.3 22.7 - - 59.3 4.5 40.4 33.9 27.4 20.9 - -
67 57.8 4.1 51.5 44.9 38.3 31.8 25.2 - 52.8 4.4 49.3 42.8 36.3 29.8 23.3 -
62 52.0 4.0 52.0 52.0 46.6 40.0 33.4 26.9 48.4 4.3 48.4 48.4 42.7 36.2 29.7 23.2
57 49.8 4.0 49.8 49.8 44.8 38.2 31.7 25.1 46.4 4.3 46.4 46.4 41.7 35.2 28.7 22.2
1750
77 73.7 4.2 37.8 29.8 22.3 - - - 68.1 4.6 37.3 27.8 20.4 - - -
72 66.8 4.1 47.3 39.7 32.2 24.7 - - 61.4 4.5 45.1 37.7 30.2 22.7 - -
67 59.9 4.1 56.7 49.7 42.2 34.7 27.2 - 54.7 4.5 52.9 47.5 40.0 32.5 25.1 -
62 53.9 4.0 53.9 53.9 51.2 43.7 36.2 28.7 50.1 4.4 50.1 50.1 47.1 39.6 32.1 24.7
57 51.6 4.0 51.6 51.6 49.3 41.8 34.2 26.7 48.1 4.4 48.1 48.1 45.9 38.5 31.0 23.5
2000
77 76.3 4.2 42.2 32.8 24.3 - - - 70.4 4.6 43.1 30.7 22.3 - - -
72 69.2 4.1 52.1 43.6 35.2 26.7 - - 63.5 4.5 49.8 41.4 33.0 24.6 - -
67 62.0 4.1 62.0 54.5 46.0 37.5 29.1 - 56.5 4.5 56.5 52.1 43.7 35.3 26.9 -
62 55.8 4.0 55.8 55.8 55.9 47.4 38.9 30.5 51.8 4.4 51.8 51.8 51.4 43.0 34.6 26.2
57 53.4 4.0 53.4 53.4 53.7 45.3 36.8 28.4 49.7 4.4 49.7 49.7 50.2 41.7 33.3 24.9
2250
72 70.6 4.2 56.4 47.1 37.7 28.4 - - 64.6 4.6 54.1 44.8 35.5 26.2 - -
67 63.3 4.1 63.3 58.7 49.4 40.1 30.7 - 57.6 4.5 57.6 55.0 47.0 37.8 28.5 -
62 57.0 4.0 57.0 57.0 57.0 47.7 38.3 29.0 52.8 4.4 52.8 52.8 52.6 43.3 34.0 24.7
57 54.5 4.0 54.5 54.5 54.7 45.4 36.0 26.7 50.6 4.4 50.6 50.6 50.8 41.6 32.3 23.0
2500
72 72.0 4.2 60.7 50.5 40.3 30.1 - - 65.8 4.6 58.3 48.2 38.0 27.9 - -
67 64.6 4.1 64.6 63.0 52.8 42.6 32.4 - 58.6 4.5 58.6 57.8 50.4 40.2 30.1 -
62 58.1 4.0 58.1 58.1 58.1 48.0 37.8 27.6 53.7 4.4 53.7 53.7 53.7 43.6 33.4 23.3
57 55.7 4.0 55.7 55.7 55.7 45.5 35.3 25.1 51.5 4.4 51.5 51.5 51.5 41.4 31.2 21.1
