528150-YTG-G-1210
Johnson Controls Unitary Products 41
ZH078 (6.5 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
1625
77 100.1 4.7 38.5 33.6 28.8 - - - 98.1 5.3 39.7 32.9 26.1 - - -
72 92.7 4.7 49.4 44.5 39.7 34.9 - - 89.4 5.3 50.8 44.0 37.2 30.4 - -
67 85.4 4.7 60.2 55.4 50.6 45.7 40.9 - 80.6 5.2 61.9 55.1 48.3 41.5 34.7 -
62 74.8 4.7 74.8 69.6 61.2 56.4 51.6 46.7 72.6 5.2 72.6 68.6 58.8 52.1 45.3 38.5
1950
77 105.7 4.7 47.6 39.7 31.8 - - - 102.0 5.3 44.7 36.8 28.8 - - -
72 97.9 4.7 59.7 51.8 43.9 35.9 - - 92.9 5.3 57.0 49.0 41.0 33.1 - -
67 90.1 4.7 71.7 63.8 55.9 48.0 40.1 - 83.9 5.3 69.2 61.2 53.3 45.3 37.3 -
62 79.0 4.7 79.0 75.6 67.6 59.7 51.8 43.9 75.5 5.2 75.5 72.8 64.9 56.9 48.9 41.0
57 77.8 4.7 77.8 79.4 72.1 64.2 56.3 48.4 75.3 5.2 75.3 75.3 67.7 59.7 51.7 43.8
2275
77 111.4 4.7 56.8 45.8 34.8 - - - 105.9 5.3 49.8 40.6 31.5 - - -
72 103.1 4.7 70.0 59.0 48.0 37.0 - - 96.5 5.3 63.1 54.0 44.8 35.7 - -
67 94.8 4.8 83.2 72.2 61.2 50.2 39.2 - 87.1 5.3 76.5 67.3 58.2 49.1 39.9 -
62 83.3 4.7 83.3 81.5 74.1 63.1 52.1 41.1 78.4 5.2 78.4 77.1 70.9 61.7 52.6 43.5
57 82.0 4.7 82.0 82.8 78.9 67.9 56.9 46.0 78.2 5.2 78.2 78.2 74.0 64.8 55.7 46.5
2600
77 117.0 4.7 66.0 51.9 37.8 - - - 109.8 5.3 54.8 44.5 34.1 - - -
72 108.3 4.7 80.3 66.2 52.2 38.1 - - 100.1 5.3 69.3 58.9 48.6 38.3 - -
67 99.5 4.8 94.6 80.5 66.5 52.4 38.4 - 90.3 5.3 83.8 73.4 63.1 52.8 42.5 -
62 87.5 4.7 87.5 87.5 80.5 66.4 52.4 38.3 81.3 5.2 81.3 81.3 76.9 66.6 56.3 45.9
57 86.2 4.7 86.2 86.2 85.7 71.7 57.6 43.6 81.1 5.2 81.1 81.1 80.2 69.9 59.6 49.3
2925
72 110.3 4.7 82.3 69.0 55.6 42.3 - - 102.7 5.3 74.5 63.2 51.8 40.5 - -
67 101.4 4.8 99.0 84.2 70.9 57.6 44.2 - 92.7 5.3 89.4 78.6 67.3 55.9 44.6 -
62 89.1 4.7 89.1 89.1 85.6 72.3 58.9 45.6 83.4 5.3 83.4 83.4 81.2 69.9 58.5 47.2
57 87.7 4.7 87.7 87.7 87.5 74.2 60.9 47.5 83.3 5.2 83.3 83.3 82.8 71.5 60.1 48.8
3250
72 112.3 4.7 84.4 71.7 59.1 46.5 - - 105.4 5.3 79.8 67.4 55.0 42.7 - -
67 103.3 4.7 103.3 88.0 75.3 62.7 50.1 - 95.1 5.3 95.1 83.8 71.4 59.1 46.7 -
62 90.7 4.7 90.7 90.7 90.7 78.1 65.5 52.8 85.6 5.3 85.6 85.6 85.6 73.2 60.8 48.4
57 89.3 4.7 89.3 89.3 89.3 76.7 64.1 51.4 85.4 5.3 85.4 85.4 85.4 73.1 60.7 48.3
95°F 105°F
1625
77 96.1 5.9 41.0 32.2 23.5 - - - 87.2 6.5 36.1 29.5 21.5 - - -
72 86.0 5.8 52.3 43.5 34.8 26.0 - - 78.4 6.3 48.5 40.4 32.4 24.4 - -
67 75.9 5.8 63.6 54.8 46.1 37.3 28.6 - 69.5 6.2 60.8 51.4 43.4 35.4 27.4 -
62 70.3 5.8 70.3 67.6 56.5 47.7 39.0 30.2 63.1 6.1 63.1 61.7 53.8 45.8 37.8 29.8
1950
77 98.3 6.0 41.8 33.8 25.8 - - - 89.3 6.5 39.9 31.7 23.6 - - -
72 88.0 5.9 54.3 46.2 38.2 30.2 - - 80.2 6.4 51.9 43.8 35.7 27.6 - -
67 77.7 5.8 66.7 58.7 50.6 42.6 34.6 - 71.2 6.3 64.0 55.9 47.8 39.7 31.5 -
62 71.9 5.8 71.9 70.1 62.1 54.1 46.0 38.0 64.6 6.2 64.6 63.7 59.2 51.1 43.0 34.8
57 72.8 5.7 72.8 71.3 63.3 55.3 47.2 39.2 67.1 6.2 67.1 66.3 58.2 50.1 41.9 33.8
2275
77 100.5 6.0 42.7 35.4 28.1 - - - 91.3 6.5 43.6 34.0 25.8 - - -
72 89.9 5.9 56.3 49.0 41.7 34.4 - - 82.1 6.4 55.4 47.2 38.9 30.7 - -
67 79.4 5.8 69.8 62.5 55.2 47.9 40.6 - 72.8 6.3 67.2 60.4 52.1 43.9 35.7 -
62 73.5 5.8 73.5 72.6 67.7 60.4 53.1 45.8 66.1 6.2 66.1 65.6 64.6 56.4 48.1 39.9
57 74.5 5.7 74.5 73.7 69.0 61.7 54.4 47.1 68.7 6.2 68.7 68.3 63.5 55.3 47.0 38.8
2600
77 102.6 6.0 43.6 37.0 30.4 - - - 93.4 6.5 47.4 36.3 27.9 - - -
72 91.9 5.9 58.2 51.7 45.1 38.5 - - 83.9 6.4 58.9 50.6 42.2 33.8 - -
67 81.1 5.8 72.9 66.3 59.8 53.2 46.6 - 74.5 6.3 70.4 64.8 56.5 48.1 39.8 -
62 75.1 5.8 75.1 75.1 73.3 66.7 60.2 53.6 67.5 6.2 67.5 67.5 70.0 61.6 53.3 44.9
57 76.1 5.8 76.1 76.1 74.7 68.1 61.6 55.0 70.2 6.2 70.2 70.2 68.8 60.5 52.1 43.7
2925
72 95.2 5.9 66.8 57.4 48.0 38.7 - - 86.3 6.5 65.6 55.3 45.1 34.8 - -
67 84.0 5.8 79.9 73.0 63.7 54.3 45.0 - 76.6 6.3 74.5 69.9 60.4 50.1 39.9 -
62 77.8 5.8 77.8 77.8 76.9 67.5 58.2 48.8 69.4 6.2 69.4 69.4 70.7 60.4 50.2 39.9
57 78.8 5.8 78.8 78.8 78.1 68.8 59.4 50.1 72.2 6.3 72.2 72.2 71.5 61.2 51.0 40.7
3250
72 98.5 5.9 75.3 63.1 51.0 38.8 - - 88.6 6.5 72.3 60.1 48.0 35.8 - -
67 87.0 5.9 87.0 79.7 67.6 55.4 43.3 - 78.6 6.4 78.6 75.0 64.2 52.1 40.0 -
62 80.5 5.9 80.5 80.5 80.5 68.4 56.2 44.1 71.3 6.3 71.3 71.3 71.3 59.2 47.1 34.9
57 81.6 5.8 81.6 81.6 81.6 69.4 57.3 45.1 74.1 6.3 74.1 74.1 74.1 62.0 49.9 37.7
